R911308501 (MKE047B-144-CP1-BENN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MKE series servo motor R911308501 (MKE047B-144-CP1-BENN) is engineered for applications in potentially explosive environments, compliant with ATEX standards. It features high dynamic response and overload capability, supporting continuous start-stop operation and maintaining maximum torque across a wide speed range. This model offers a continuous torque of 2.7 Nm and a peak torque of 11.3 Nm, with a maximum speed of 7000 RPM. The integrated optical encoder, type M1 (multiturn absolute, Hiperface protocol, 128 increments), enables precise position feedback. The unit includes a 2.2 Nm holding brake and utilizes a shaft with keyway (DIN 6885) and shaft seal. Electrical connections are provided via a terminal box on the B-side. The device is rated for insulation class 155 (F), incorporates 4 pole pairs, and operates within an ambient temperature range of 0 to 40°C. The housing complies with IP65 protection standards.

Technical Specifications

Product Type
Servo Motor

Potential Usage Areas
Areas with explosion potential

Rated Maximum Speed
7000 RPM

Encoder Type
Optical Encoder

Encoder Protocol
Hiperface

Encoder Increments
128

Electrical Connection
Terminal Box on Side B

Optimal Ambient Temperature
0-40 degrees Celsius

Continuous Torque
2.7 Nm

Maximum Torque
11.3 Nm

Housing Rating
IP 65

Installation
Can be installed in any orientation

Global Shipment
Available
