R911308805 (MKE047B-144-GG1-BENN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911308805 (MKE047B-144-GG1-BENN) is a servo motor designed for potentially explosive environments, compliant with ATEX housing standards and insulation class 155 (F). This motor features a compact design with a length of 287 mm, a thickness of 78 mm, and a weight of 5.5 kg. It supports a maximum rotational speed of 7000 RPM and draws up to 22.6 A. The unit incorporates a plain steel shaft with a DIN 332 'DS' thread, frontal centering hole, and shaft seal. It is equipped with a holding brake providing 2.2 Nm, has four pole pairs, and its connections are arranged on the B-side via an integrated terminal box.

Technical Specifications

Rexroth Indramat Producer
Yes

Protection Class
IP65

Coating
Prime Black Coat

Designs Available
Design E, Design U

Shaft Material
Steel

Maximum Speed
7000 revolutions per minute

Maximum Current
22.6 Amperes

Weight
5.5 kilograms

Length
287 millimeters

Thickness
78 millimeters

Shipping
Global

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the MKE047B-144-GG1-BENN.
