R911314014 (MKE047B-144-CG0-BENN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth synchronous motor R911314014 (MKE047B-144-CG0-BENN) is designed with a corrosion-resistant black paint finish suitable for environments exposed to mineral oils, seawater, and diluted acids. The motor uses a plain shaft with a DIN 332 compliant 'DS' thread and frontal centering hole, and includes a shaft seal. It features durable bearings rated for a lifespan of 30,000 hours, supporting both axial and radial loads. R911314014 is ATEX-compliant for potentially explosive areas and employs a terminal box connection on the B-side. The unit's insulation class is 155 (F) per DIN EN 60034-1, and it operates with four pole pairs and a winding code of 144. An M1 optical multiturn absolute Hiperface encoder (128 increments) is fitted. Thermal performance is affected when used with a gearbox. Storage temperatures range from -20°C to 60°C. Professional installation and maintenance are required.

Technical Specifications

Color
Black

Mounting Position
IM V3

Shaft Type
Plain

Running Smoothness
Excellent

Shaft Wear
Potential in Intense Reversing Operation

Bearing Load Type
Axial and Radial

Bearing Lifespan
30,000 Operating Hours

Heat Dissipation
Reduced via Flange

Insulation Class
155

Storage Temperature
-20°C to 60°C

Compliance
DIN EN 60034-1, EN 60204-1

Identification
Secondary Type Plate

Transport Requirement
Shock Absorbers for Shock Vibration

Professional Installation
Required

Mounting Screw Type
M6 x 20

Tightening Torque
10.4Nm
