R911314949 (MKE047B-144-AG0-BINN)

Type
Synchronous Servo Motor

Frame Size
047

Winding
144

Frame Length
B

Encoder Design
12-bit Optical Absolute Single-turn

Interface
Hiperface

Max Encoder Speed
12,000 min-1

System Accuracy
120 angular seconds

Max current consumption
60mA

Holding Brake
No

Terminal Box Position
B-side

Continuous Torque at standstill 60K
2.7 Nm

Continuous Current
5.0 A

Max Torque
11.3 Nm

Max Current
22.6 A

Winding Resistance
5.0 Ohms

Torque Constant
0.59 Nm/A

Voltage Constant
36.3 V/min-1

Magnetic Poles
3 pairs

Thermal Time Constant
30.0 minutes

Moment of Inertia
0.00017 kgm2

Ingress Protection Rating
IP 65

Insulation Class
155

Ambient Operating Temperature
0 to 40 degC

Installation Altitude
1000 m

Weight
5.5 kg
