R911316652 (MKE047B-144-CG1-BENN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911316652 (MKE047B-144-CG1-BENN) from Bosch Rexroth is a brushless servo motor designed for use in potentially explosive environments, compliant with ATEX standards. Featuring a Multiturn absolute Hiperface optical encoder (128 increments, model M1), this motor operates at a voltage range of DC 580–750 V, offering a continuous current of 5 A. It provides a standstill torque of 2.7 Nm and is equipped with a 2.2 Nm holding brake. The motor features a shaft with a frontal centering hole and DIN 332 DS thread, plain shaft design, and shaft seal. The unit has a terminal box connection on the B-side, winding type 144, motor size 47, and weighs 5.5 kg. It supports an optimum speed of 7000 rpm, operates within an ambient temperature of 0 to +40 °C, and uses insulation class 155 (F). Installation should be performed according to the user manual to ensure proper function.

Technical Specifications

Product Type
Servo Motor

Encoder Type
12-bit Multiturn absolute Hiperface Optical

Encoder Supply Voltage
7 - 12 V

Motor Operating Voltage
DC 580 - 750 V

Winding Voltage
36.3 V

Winding Resistance
5 Ohm

Torque
0.59 Nm/A

Operating Temperature
20 degree Celsius

Current
5 A

Continuous Torque at Standstill
2.7 Nm

Weight
5.5 kg

Max Velocity
7000 rpm

Operating Temperature Range
0 to +40 degree Celsius

Mounting Material
Insulated Aluminum Flange

Shaft Sealing Ring
Yes

Holding Brake Torque
2.2 Nm

Holding Brake Rated Voltage
24 V

Holding Brake Current
0.34 A

Brake Connection Time
14 ms

Brake Disconnection Time
28 ms
