R911317211 (MKE047B-144-AG0-BUNN)

MKE Synchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The MKE047B-144-AG0-BUNN (MPN: R911317211) is a servo motor engineered for applications requiring precise control of speed, torque, and position. It provides a constant standstill torque of 2.7 Nm and a peak torque of 11.3 Nm, operating at up to 7000 rpm. The motor features a plain shaft with a frontal centering hole, includes a shaft seal, and uses a DIN 332 compliant 'DS' thread. Equipped with a Singleturn Hiperface optical encoder (S1) with 128 increments, the device adheres to IP65 protection and UL/CSA standards. The connection is on the B-side via a terminal box. The motor is designed with four pole pairs, insulation class 155 (F), size 47, and winding 144, and operates at a typical noise level of 63 dB(A).

Technical Specifications

Product Type
Servo Motor

Mass
5.5 kg

Continuous Torque
2.7 Nm

Maximum Torque
11.3 Nm

Maximum Speed
7000 rpm

Protection Standard
IP65

Housing Design Standard
UL

Encoder Type
Singleturn Hiperface Optical Encoder

Noise Level
63 db(A)
