R911321710 (MKE047B-144-AP0-BENN)

MKE Synchronous Motors

  Call For Quote
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth servo motor R911321710 (MKE047B-144-AP0-BENN) delivers a continuous standstill current of 5 A and a torque output of 2.7 Nm at 60 K overtemperature, with a peak torque of 11.3 Nm. Designed for use in potentially explosive environments, this motor is housed in an ATEX-compliant enclosure rated IP65, ensuring protection against dust and water ingress. The configuration features a terminal box connection on the B-side, shaft with DIN 6885 keyway and shaft seal, and includes an optical single-turn Hiperface absolute encoder (model S1, 128 increments) for enhanced position feedback. The unit operates with a winding code of 144, has four pole pairs, follows insulation class 155 (F), and its bearings are grease-lubricated. Servomotor mounting complies with DIN standards.

Technical Specifications

Operating Feature
Reliable during operation

Continuous Current During Standstill
5 A

Torque at 60 K
2.7 Nm

Torque Constant at 20 ᵒC
0.59 Nm/A

Max Torque
11.3 Nm

Winding Resistance at 20 ᵒC
5 ohms

Interface Compatibility
Hiperface

Encoder Type
Single-turn absolute

Mounting Compatibility
Flange in compliance with relevant DIN standards
