R911323336 (MKE047B-144-CP0-BUNN)

MKE Synchronous Motors

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911323336 (MKE047B-144-CP0-BUNN) is a globally-approved, MKE series synchronous motor, specifically crafted for potentially hazardous areas in compliance with UL/CSA and ATEX standards. Suitable to partner with Rexroth drives, it offers advanced functionality in potentially explosive areas. The motor is IP 65 protected, featuring a temperature tolerance of 0-40 degrees Celsius during operation. The motor offers optimal size (047) and length (B) dimensions, along with a 144-winding code. It is equipped with an optical multiturn encoder with 128 increments and a DIN 6885-1 shaft with a sealing ring. While the model lacks an in-built brake, a separately orderable holding brake is offered by Bosch. Connection is through a side-B located terminal box and the unit complies with UL housing design standards. Weighing in at about 5.5 kilograms, it has 3 pole pairs and delivers a maximum speed of 7000 RPM. Available for global shipping, it comes with a one-year warranty via Indramat USA.

Technical Specifications

Usage Design
Potentially explosive areas

Standards
UL/CSA, ATEX

Rated Continuous Torque at Standstill (60K overtemperature)
2.7 Nm

Continuous Current at Standstill (60K overtemperature)
5 Amps

Maximum Rated Current
22.6 Amps

Maximum Rated Torque
11.3 Nm

Protection Class
IP 65

Operating Ambient Temperature Range
0-40 degrees Celsius

Size
047

Length
B

Winding Code
144

Holding Brake
Not Available

Electrical Connection
Side-B Terminal Box

Housing Compliance
UL standard

Weight
5.5 kilograms

Pole Pairs
3

Max Motor Speed
7000 RPM
