R911326927 (MKE047B-144-AG1-BENN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911326927 (MKE047B-144-AG1-BENN) is a servo motor engineered for use in potentially explosive environments, conforming to ATEX housing standards. It features a plain shaft with a frontal centering hole and a DIN 332-compliant 'DS' thread, protected by a shaft seal. This model utilizes a 144 winding, 47-size frame, and contains 4 pole pairs. It is equipped with a terminal box for B-side electrical connection and integrates a holding brake rated at 2.2 Nm. The optical singleturn Hiperface encoder (S1) provides 128 increments. The motor operates with insulation class 155 (F) and supports electronic commutation for efficient torque delivery throughout a broad speed range. Noise emissions are maintained at 63 dB(A), and a temperature control system ensures stable operation at a continuous torque of 2.7 Nm and 5 A at 60 K overtemperature.

Technical Specifications

Product Type
Servo Motor

Functionality
Speed and position control in assembly line

Operating Environment
Hazardous areas

Torque to Inertia Mass Ratio
High

Temperature Control
Internal

Standstill Continuous Torque
2.7 Nm

Standstill Continuous Current
5 A

Mains Motor Overtemperature
60 K

Insulation Material
Class 155

Max Motor Speed
7000 rpm

Mass
5.5 kg

Noise Level
63 db(A)

Standards Compliance
CSA/UL, ATEX, EN

Commutation type
Electronic

Global Shipping
Available
