R911327766 (MKE047B-144-CG1-BUNN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The MPN R911327766 (MKE047B-144-CG1-BUNN) is a Bosch Rexroth brushless servo motor featuring a permanent magnet design for high-precision speed and position control. This unit is equipped with a 12-bit multiturn absolute Hiperface optical encoder (128 increments), a plain shaft with frontal centering hole, DIN 332 compliant 'DS' shaft thread, and a holding brake with 2.2 Nm brake torque. The motor supports connection via terminal box (B-side), operates within a voltage range of 580–750 V, delivers up to 11.3 Nm torque, and complies with insulation class 155 (F). It is rated for operation in ambient temperatures from 0 to +40°C, at elevations up to 1000 m, and adheres to IP65 and UL/CSA housing standards. The model includes a shaft seal and has 4 pole pairs; its weight is 5.5 kg excluding brake and mounting. Suitable for applications in potentially explosive areas.

Technical Specifications

Type
Brushless Servo Motor

Maximal Speed
9000/min

Voltage Range
580 to 750 V

Maximum Current
22.6 A

Output Torque
11.3 Nm

Shaft Type
Plain

Constant Current
5 A

Continuous Torque at Standstill
2.7 Nm

Pole Pairs
3

Operating Temperature Range
0 to +40 degree Celsius

Weight
5.5 kg

Protection Class
IP 65

Maximal Elevation
1000 meters

Compliance
American Standards

Holding Brake Voltage
24 V

Holding Brake Rated Current
0.34 A

Holding Brake Torque
2.2 Nm

Winding Inductivity
1800 mH

Winding Resistance
5 mH at 20 degree Celsius
