R911333575 (MKE047B-144-CP1-BUNN)

MKE Synchronous Motors

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911333575 (MKE047B-144-CP1-BUNN) is a Bosch Rexroth servo motor engineered for demanding position and speed control in industrial automation environments, including potentially explosive areas. This unit features a 47 motor size, 144 winding, and operates with electric commutation for a spark-free profile. Compliance with ATEX, UL, and CSA standards enables use in harsh environments. The motor achieves a maximum torque output of 11.3 Nm and includes a 2.2 Nm holding brake. It incorporates a multiturn absolute Hiperface optical encoder (128 increments, M1 model), four pole pairs, insulation class 155 (F), and a shaft with DIN 6885 keyway and seal. The terminal box connection is located on the B-side. Total weight is 5.5 kg. Maximum ambient temperature is 40°C, with continuous operation possible at higher temperatures with minor performance adjustments.

Technical Specifications

Product Type
Motion Control Products

Usage
Position Control Tasks, Speed Control Applications

Compliance
DIN, EN, ATEX, UL, CSA Standards

Design
Spark-Free, Electric Commutation

Peak Torque
11.3 Nm

Weight
5.5 kg

Design style
Ultra-Compact

Operating Temperature
Up to 40 ᵒC

Position Adjustment System
Internal Position Control Loop System

Availability
Global

Shipping
Available with Indramat USA

Common Misspellings

1620 Old Apex Road
Cary, NC 27513, USA

Toll Free: 1-888-551-3082
International: 1-919-443-0207

Fax: 1-919-867-6204

[email protected]

Shipping & Payment Options

Warranty

Indramat USA 1 Year Warranty

Repair

We offer a repair service for the MKE047B-144-CP1-BUNN.

Exchange

Want to sell your MKE047B-144-CP1-BUNN?
