R911335598 (MKE047B-144-AP0-BUNN)

MKE Synchronous Motors

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth servo motor R911335598 (MKE047B-144-AP0-BUNN) is engineered for precision motion control in demanding environments, conforming to EN, UL/CSA, and ATEX standards. This unit integrates a flange design compatible with DIN specifications, uses a brushless configuration for spark-free operation, and implements a closed-loop feedback system with a singleturn 128-increment Hiperface S1 optical encoder for position and speed accuracy. It has a shaft with a DIN 6885 keyway, shaft seal, and is wound to specification 144. The four-pole pair motor provides up to 11.3 Nm torque, weighs 5.5 kg, and employs insulation class 155 (F). The terminal box is located on the B-side, and the motor does not include a holding brake. The housing is designed to resist ingress of particulates, oils, emulsions, and water jets, supporting use in hazardous or potentially explosive areas.

Technical Specifications

Product Type
Servo Motor

Design Compliance
EN, UL/CSA, ATEX standards

Motor Brushes
Not used

Torque Capacity
11.3 Nm

Weight
5.5 kg

Ambient Temperature Tolerance
Not higher than 40°C

Feedback System
Closed loop

Ingress Protection
IP 65

Global Shipping
Available

Application
Industrial automation systems
