MS2N06-D0BRN-BMUK2-NNNNN-NN
MS2N Synchronous Servo Motors
The MS2N06-D0BRN-BMUK2-NNNNN-NN from Bosch Rexroth Indramat delivers a rated power of 1.1 kW and a rated torque of 4.6 Nm. Part of the MS2N Synchronous Servo Motors series, it operates at 3000 rpm and offers IP65 protection for demanding environments.
It uses natural convection cooling and a multi-turn encoder for precise feedback with a rated current of 5.3 A. It includes a holding brake and an M23 angle plug for robust electrical connection.
Technical Specifications
Cooling Method
Natural convection
Feedback Type
Multi-turn Encoder
Motor Size
06
Mounting Type
Flange mounting
Protection Class
IP65
Rated Current
5.3 A
Rated Power
1.1 kW
Rated Speed
3000 rpm
Rated Torque
4.6 Nm
Rated Voltage
230 V
Torque Constant at 20 degrees C
1.33 Nm/A
Type
Synchronous Servo Motor
Voltage Constant at 20 degrees C
80.5 V per 1000 rpm
Winding Inductance (minimum)
11.06 mH
Winding Resistance at 20 degrees C
1.13 ohm
Electrical Connection
M23 Angle Plug, Turnable
Holding Brake
Equipped
Shaft
Keyway, with shaft seal
Winding
4,500 min
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MS2N06-D0BRN-BMUK2-NNNNN-NN.
