MSK070D-0450-NN-S1-UP1-NNNN
MSK IndraDyn S Synchronous Motors
The Bosch Rexroth Indramat MSK070D-0450-NN-S1-UP1-NNNN from the MSK IndraDyn S Synchronous Motors series is a high-precision IndraDyn S Synchronous Servomotor featuring a motor size of 070 and a motor length of D. It delivers a maximum torque of 52.5 Nm and a holding brake torque of 23 Nm, with a constant voltage (20°C) of 71.1 V/min-1. The motor supports an optical encoder with Hiperface interface, 128 signal periods resolution and rotatable, 240° connector. It employs natural convection cooling and a shaft with keyway per DIN 6885-1. With a Winding Code of 0450, this standard design unit achieves a continuous current of 22.0 A and torque of 20.0 Nm at standstill 100 K, ensuring reliable and customizable performance for demanding industrial applications.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Interface
Hiperface
Encoder Resolution
128 signal periods
Encoder Technology
Optical
Encoder Turn Type
Singleturn
Motor Length
D
Motor Size
070
Holding Brake
With holding brake, electrically-released
Holding Brake Torque
23 Nm
Design
Standard
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Shaft with keyway
Winding Code
0450
Continuous Current at Standstill 100 K
22.0 A
Continuous Torque at Standstill 100 K
20.0 Nm
Maximum Current
49.8 A
Maximum Torque
52.5 Nm
Winding Inductivity
3,000 mH
Frequently Asked Questions
Why is this servomotor ideal for demanding industrial applications?
It combines high torque, precise encoder feedback, holding brake, and reliable current handling. These ensure accurate and repeatable motion control.
How does the winding code 0450 impact performance?
The motor design defines electrical values including inductance. It ensures stable torque and consistent behavior.
Why is the motor suitable for CNC and packaging applications?
It delivers precise torque, accurate position feedback, and repeatable performance. It meets high-precision motion requirements.
How does the Hiperface interface improve feedback reliability?
It provides digital absolute position data. This ensures precise control and reliable communication with drives.
Why is the motor without fan-driven cooling advantageous?
No fans reduce mechanical complexity and maintenance. It minimizes moving parts and extends operational lifespan.
Common Misspellings
MSK 070D-0450-NN-S1-UP1-NNNN
MSK-070D-0450-NN-S1-UP1-NNNN
MSK070D 0450 NN S1 UP1 NNNN
MSK070D-0450-NN-S1-UP1
MSK070D-0450-NN-SI-UPI-NNNN
MSK070D0450NNS1UP1NNNN
MSKO70D-0450-NN-S1-UP1-NNNN
MSKO7OD-O45O-NN-S1-UP1-NNNN
msk070d-0450-nn-s1-up1-nnnn
MSK070D0450NNS1UP1NNNN
MSK070D 0450 NN S1 UP1 NNNN
MSK70D-0450-NN-S1-UP1-NNNN
Internal Product Review
The MSK070D-0450-NN-S1-UP1-NNNN synchronous servomotor by Bosch Rexroth delivers 20.0 Nm continuous and 52.5 Nm maximum torque with a 22.0 A standstill current. It features an optical singleturn encoder using the Hiperface interface and a shaft with keyway. Ideal for CNC machinery, robotics, and printing applications requiring precise motion control with natural convection cooling.
