MSK070E-0150-NN-M2-UP0-RNNN
MSK IndraDyn S Synchronous Motors
The MSK070E-0150-NN-M2-UP0-RNNN from Bosch Rexroth Indramat features an increased concentricity design and a shaft with keyway. Part of the MSK IndraDyn S Synchronous Motors, it uses natural convection cooling and an optical encoder. The multiturn absolute encoder supports EnDat2.1 with 2048 signal periods and the motor size code is 070.
It delivers continuous torque of 25.0 Nm at a standstill current of 7.0 A and reaches maximum torque of 70.0 Nm. The maximum current is 25.6 A. It is without holding brake.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Technology
Optical
Encoder Turn Type
Multiturn Absolute
Encoder Interface
EnDat2.1
Encoder Resolution
2048 signal periods
Motor Length
E
Motor Size
070
Holding Brake
Without holding brake
Design
Increased concentricity
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Shaft with keyway
Rated Speed Code
0150
Continuous Current at Standstill 100 K
7.0 A
Continuous Torque at Standstill 100 K
25.0 Nm
Maximum Current
25.6 A
Maximum Torque
70.0 Nm
Winding Inductivity
24,500 mH
Frequently Asked Questions
Does MSK070E-0150-NN-M2-UP0-RNNN include a brake system?
No, MSK070E-0150-NN-M2-UP0-RNNN is supplied without a brake.
What is the design type of MSK070E-0150-NN-M2-UP0-RNNN?
The MSK070E-0150-NN-M2-UP0-RNNN is made with increased concentricity design.
What continuous torque does MSK070E-0150-NN-M2-UP0-RNNN deliver at standstill?
The MSK070E-0150-NN-M2-UP0-RNNN provides 25.0 Nm torque at standstill.
What is the motor length for MSK070E-0150-NN-M2-UP0-RNNN?
MSK070E-0150-NN-M2-UP0-RNNN is manufactured with motor length code E.
What is the rated speed code for MSK070E-0150-NN-M2-UP0-RNNN?
The rated speed code for MSK070E-0150-NN-M2-UP0-RNNN is 0150.
Common Misspellings
MSK070E0150NNM2UP0RNNN
MSK070E 0150 NN M2 UP0 RNNN
MSK-070E-0150-NN-M2-UP0-RNNN
MSK70E-0150-NN-M2-UP0-RNNN
Internal Product Review
The MSK070E-0150-NN-M2-UP0-RNNN demonstrates steady operation across extended workloads. Its construction emphasizes stability and dependable service. The motor provides consistent results during long-term use, supporting integration into different applications. With performance maintained over time, it proves effective for demanding environments requiring continuous operation and durable outcomes across challenging and extended usage requirements.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MSK070E-0150-NN-M2-UP0-RNNN.
