MSK070E-0300-NN-M1-UP1-NSNN
MSK IndraDyn S Synchronous Motors
The MSK070E-0300-NN-M1-UP1-NSNN is an IndraDyn S Synchronous Servomotor by Bosch Rexroth Indramat, part of the MSK IndraDyn S Synchronous Motors series. It uses natural convection cooling and an optical multiturn absolute encoder with a Hiperface interface and 128 signal periods resolution. The motor delivers 25.0 Nm continuous torque at standstill (100 K) with 16.7 A and peaks at 65.0 Nm with 49.3 A. A shaft with keyway and electrically released 23 Nm holding brake complete the design.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Technology
Optical
Encoder Turn Type
Multiturn Absolute
Encoder Interface
Hiperface
Encoder Resolution
128 signal periods
Motor Length
E
Motor Size
070
Holding Brake
With holding brake, electrically-released
Holding Brake Torque
23 Nm
Design
Standard and Explosion Protection
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Shaft with keyway
Rated Speed Code
0300
Continuous Current at Standstill 100 K
16.7 A
Continuous Torque at Standstill 100 K
25.0 Nm
Maximum Current
49.3 A
Maximum Torque
65.0 Nm
Winding Inductivity
3,900 mH
Frequently Asked Questions
Why is the motor designed with explosion protection?
The explosion protection design ensures safe operation in hazardous environments. This prevents potential risks associated with volatile atmospheres that maintains motor integrity.
How does the keyway shaft design enhance motor performance?
The keyway shaft ensures secure mechanical connection. This prevents slippage and improves reliability in torque transmission during operation.
Why is a rotatable encoder connector used in this motor?
The 240° rotatable encoder connector allows flexible installation. This ensures easy alignment, making the motor adaptable to different configurations.
What benefits does the 23 Nm holding brake provide in this motor?
The electrically released 23 Nm holding brake secures the motor’s position when powered off. This ensures safety and stability during standstill.
Why does this motor have natural convection cooling?
Natural convection cooling enhances thermal management without external fans. This provides energy-efficient cooling and increases the motor's lifespan.
Common Misspellings
MSK070E0300NNM1UP1NSNN
MSK070E 0300 NN M1 UP1 NSNN
MSK-070E-0300-NN-M1-UP1-NSNN
MSK70E-0300-NN-M1-UP1-NSNN
Internal Product Review
The Bosch Rexroth Indramat MSK070E-0300-NN-M1-UP1-NSNN synchronous motor features an optical multiturn absolute encoder with a Hiperface interface. It delivers 25 Nm continuous torque and 65 Nm maximum torque. With an electrically-released 23 Nm holding brake, it excels in automated assembly and high-precision robotic applications.
