MSK070E-0300-NN-M2-UP1-RNNN
MSK IndraDyn S Synchronous Motors
The MSK070E-0300-NN-M2-UP1-RNNN is an IndraDyn S Synchronous Servomotor by Bosch Rexroth Indramat in the MSK IndraDyn S Synchronous Motors series. Featuring an optical EnDat2.1 encoder with 2048 signal periods resolution and multiturn absolute turn type, this size 070, length E motor delivers 25.0 Nm continuous torque (16.7 A) and 65.0 Nm maximum torque (49.3 A). It includes an electrically-released holding brake rated 23 Nm, employs natural convection cooling, and offers increased concentricity and a shaft with keyway.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Technology
Optical
Encoder Turn Type
Multiturn Absolute
Encoder Interface
EnDat2.1
Encoder Resolution
2048 signal periods
Motor Length
E
Motor Size
070
Holding Brake
With holding brake, electrically-released
Holding Brake Torque
23 Nm
Design
Increased concentricity
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Shaft with keyway
Rated Speed Code
0300
Continuous Current at Standstill 100 K
16.7 A
Continuous Torque at Standstill 100 K
25.0 Nm
Maximum Current
49.3 A
Maximum Torque
65.0 Nm
Winding Inductivity
3,900 mH
Frequently Asked Questions
What advantage does the 240° rotatable encoder connector offer?
The 240° rotatable encoder connector provides flexible mounting options. This helps with motor integration in various configurations or limited-space installations.
How does the natural convection cooling system support motor longevity?
Natural convection cooling reduces overheating risks. This supports longer motor life and consistent performance in environments with low airflow.
How does the 2048 signal periods encoder resolution affect feedback precision?
The 2048 signal period encoder resolution ensures ultra-fine position tracking. This allows for more accurate and responsive control over motor movements.
Why is a multiturn encoder beneficial in high-demand industrial applications?
A multiturn encoder tracks position over multiple rotations. This ensures accurate feedback even in systems requiring continuous, high-precision motion.
How does the increased concentricity affect motor vibration?
Increased concentricity ensures more even rotation. This minimizes vibration that improves smoothness and reducing wear on motor components.
Common Misspellings
MSK070E0300NNM2UP1RNNN
MSK070E 0300 NN M2 UP1 RNNN
MSK-070E-0300-NN-M2-UP1-RNNN
MSK70E-0300-NN-M2-UP1-RNNN
Internal Product Review
The Bosch Rexroth Indramat MSK070E-0300-NN-M2-UP1-RNNN synchronous motor delivers 25 Nm continuous torque and 65 Nm maximum torque. The motor includes an EnDat2.1 optical encoder and an electrically-released 23 Nm holding brake. It suits high-demand applications in robotics, packaging, and CNC machinery.
