MSK070E-0300-NN-M3-UG1-NNNN
MSK IndraDyn S Synchronous Motors
The Bosch Rexroth Indramat MSK070E-0300-NN-M3-UG1-NNNN servomotor from the MSK IndraDyn S Synchronous Motors series is a robust IndraDyn S Synchronous Servomotor featuring a plain shaft design and natural convection cooling. It has a motor size of 070 with length E and a rated speed code of 0300. Equipped with a capacitive multiturn absolute encoder offering Hiperface interface and 16 signal periods resolution via a rotatable 240° connector, it delivers a continuous torque of 25.0 Nm at a standstill current of 16.7 A. Its holding brake is electrically-released with 23 Nm braking torque. The winding inductivity is 3,900 mH, with a maximum torque of 65.0 Nm and a maximum current of 49.3 A.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Technology
Capacitive
Encoder Turn Type
Multiturn Absolute
Encoder Interface
Hiperface
Encoder Resolution
16 signal periods
Motor Length
E
Motor Size
070
Holding Brake
With holding brake, electrically-released
Holding Brake Torque
23 Nm
Design
Standard
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Plain shaft
Rated Speed Code
0300
Continuous Current at Standstill 100 K
16.7 A
Continuous Torque at Standstill 100 K
25.0 Nm
Maximum Current
49.3 A
Maximum Torque
65.0 Nm
Winding Inductivity
3,900 mH
Frequently Asked Questions
What cooling method is used in the MSK070E-0300-NN-M3-UG1-NNNN motor?
The MSK070E-0300-NN-M3-UG1-NNNN motor uses natural convection cooling. This ensures efficient heat dissipation without external cooling systems.
How does the 49.3 A maximum current impact the MSK070E-0300-NN-M3-UG1-NNNN motor’s performance?
The 49.3 A maximum current allows the MSK070E-0300-NN-M3-UG1-NNNN motor to handle high torque demands that provides rapid acceleration and deceleration when needed.
What is the role of the 16 signal periods encoder resolution in the MSK070E-0300-NN-M3-UG1-NNNN motor?
The 16 signal periods encoder resolution ensures precise position tracking. This helps the motor deliver accurate feedback in dynamic control systems.
How does the 240° rotatable encoder connector benefit the MSK070E-0300-NN-M3-UG1-NNNN motor installation?
The 240° rotatable encoder connector provides flexibility during installation. It allows for easier adjustment and alignment, particularly in tight spaces.
Does the MSK070E-0300-NN-M3-UG1-NNNN motor include a holding brake?
Yes, the MSK070E-0300-NN-M3-UG1-NNNN motor comes with an electrically-released holding brake. It has a braking torque of 23 Nm.
Common Misspellings
MSK070E0300NNM3UG1NNNN
MSK070E 0300 NN M3 UG1 NNNN
MSK-070E-0300-NN-M3-UG1-NNNN
MSK70E-0300-NN-M3-UG1-NNNN
Internal Product Review
The MSK070E-0300-NN-M3-UG1-NNNN synchronous motor provides 25 Nm continuous torque and 65 Nm maximum torque. It features an optical encoder with a Hiperface interface and natural convection cooling. The synchronous motor is ideal for industrial applications in robotics and CNC machinery.
