MSK071D-0450-NN-S3-UP0-NNNN
MSK IndraDyn S Synchronous Motors
The MSK071D-0450-NN-S3-UP0-NNNN is an IndraDyn S Synchronous Servomotor by Bosch Rexroth Indramat from the MSK IndraDyn S Synchronous Motors series. It provides a continuous torque of 20.0 Nm at standstill with 17.6 A and peaks at 66.0 Nm with 69.3 A. The motor features a capacitive singleturn encoder with Hiperface interface and a rotatable 240° connector, uses natural convection cooling, and incorporates a shaft with keyway in a standard frame design.
Technical Specifications
Cooling
Natural convection
Encoder Connector
Rotatable, 240°
Encoder Technology
Capacitive
Encoder Turn Type
Singleturn
Encoder Interface
Hiperface
Encoder Resolution
16 signal periods
Motor Length
D
Motor Size
071
Holding Brake
Without holding brake
Design
Standard
Product Type
IndraDyn S Synchronous Servomotor
Shaft Type
Shaft with keyway
Rated Speed Code
0450
Continuous Current at Standstill 100 K
17.6 A
Continuous Torque at Standstill 100 K
20.0 Nm
Maximum Current
69.3 A
Maximum Torque
66.0 Nm
Winding Inductivity
3,200 mH
Frequently Asked Questions
Is a holding brake installed on the motor?
The motor with without a holding brake.
What is the sound pressure level of the motor?
The sound pressure level does not exceed 75 dB.
What is the maximum motor speed?
Maximum speed of the servo motor is 6000 RPM.
What is the insulation class of the motor?
Insulation class of the motor is F.
Is the power plug rotatable?
The power plug can be rotated 240 degrees.
Common Misspellings
MSK071D0450NNS3UP0NNNN
MSK071D 0450 NN S3 UP0 NNNN
MSK-071D-0450-NN-S3-UP0-NNNN
MSK71D-0450-NN-S3-UP0-NNNN
Internal Product Review
MSK071D-0450-NN-S3-UP0-NNNN is a motor designed for convection cooling. Its features include IP65 housing, keyed shaft and singleturn encoder. The motor is optimized for applications requiring accurate speed control.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MSK071D-0450-NN-S3-UP0-NNNN.
