MSK076C-0300-NN-S1-UG1-NNNN Series Image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

6 Minutes 35 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The MSK076C-0300-NN-S1-UG1-NNNN from Bosch Rexroth Indramat features a motor size of 076 and a holding brake torque of 11 Nm. Part of the MSK IndraDyn S Synchronous Motors, it delivers a maximum torque of 43.5 Nm and a continuous torque of 13.5 Nm. This servomotor uses optical singleturn encoder technology with a Hiperface interface.

It cools by natural convection and features a plain shaft design. Encoder connector is rotatable 240°. Maximum current is 32.4 A.

Technical Specifications

Cooling
Natural convection

Encoder Connector
Rotatable, 240°

Encoder Technology
Optical

Encoder Turn Type
Singleturn

Encoder Interface
Hiperface

Encoder Resolution
128 signal periods

Motor Length
C

Motor Size
076

Holding Brake
With holding brake, electrically-released

Holding Brake Torque
11 Nm

Design
Standard

Product Type
IndraDyn S Synchronous Servomotor

Shaft Type
Plain shaft

Rated Speed Code
0300

Continuous Current at Standstill 100 K
8.1 A

Continuous Torque at Standstill 100 K
13.5 Nm

Maximum Current
32.4 A

Maximum Torque
43.5 Nm

Winding Inductivity
12,600 mH

Frequently Asked Questions

How does the Hiperface singleturn optical encoder in MSK076C-0300-NN-S1-UG1-NNNN aid servo precision and loop stability?

The Hiperface protocol carries absolute position per revolution with analog commutation plus digital data for improving interpolation and low-speed smoothness; optical sensing minimizes drift. It enhances current/velocity loops and simplifies drive commissioning with IndraDrive controllers.

How is the 13.5 Nm continuous torque at standstill (100 K) on MSK076C-0300-NN-S1-UG1-NNNN used in high-precision holding and low-speed feed axes?

At stall, the thermal model ensures continuous current capacity for creep feeds and dwell cycles without overheating. Its drive can overlay closed-loop control with the brake for secure holding during e-stop or vertical load retention.

How does the 32.4 A maximum current capability translate to motion profiles on MSK076C-0300-NN-S1-UG1-NNNN?

The peak current enables short-duration torque bursts up to the 43.5 Nm limit for fast indexing, acceleration or disturbance rejection. Its tuning follows time-at-peak and thermal limits dictated by the motor’s characteristic curves.

How does the electrically-released 11 Nm holding brake on MSK076C-0300-NN-S1-UG1-NNNN support vertical axes and safe torque-off strategies?

The spring-applied brake secures the load when power is removed or during STO to prevent drift on Z-axes. Its control logic blends torque hold and brake timing to avoid shock while meeting safety concepts.

What are integration considerations for the plain-shaft design on MSK076C-0300-NN-S1-UG1-NNNN in precision couplings or gearheads?

The plain shaft simplifies zero-backlash coupling selection and concentric gearhead mounting while minimizing runout-induced ripple. Its proper hub-bore fits, keyless locking and alignment practices to preserve encoder fidelity and servo smoothness.

Common Misspellings

Internal Product Review

The MSK076C-0300-NN-S1-UG1-NNNN servomotor features 13.5 Nm continuous torque and 43.5 Nm peak. It uses natural-convection cooling and uses a Hiperface optical singleturn encoder for precise positioning. This unit has a frame size of 076 and possess a plain shaft design. It comes with an electrically-released 11 Nm brake that suits packaging, machine tools and printing lines. Its maximum current capacity is up to 32.4 A to support energetic moves.
