R911299955 (MSK070D-0450-NN-M2-UP0-RNNN)

Name: R911299955 (MSK070D-0450-NN-M2-UP0-RNNN)
Brand: Indramat Motors
SKU: MSK070D-0450-NN-M2-UP0-RNNN
Price: 402.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth R911299955 (MSK070D-0450-NN-M2-UP0-RNNN) is an MSK series synchronous servomotor designed for precise control in industrial applications such as metal forming, woodworking, food processing, and paper production. It features class 155 insulation, IP65 ingress protection, and a shaft with keyway. This motor operates with a continuous torque of 20.0 Nm (standstill, 100 K), and a maximum torque of 52.5 Nm at up to 6000 rpm. Continuous current at standstill is rated at 22.0 A (100 K), with a maximum current of 49.8 A. The winding inductivity is 3.0 mH and the discharge capacity is 4.5 nF. It includes an optical multiturn absolute encoder (EnDat2.1) with 2048 signal periods and a rotatable 240° encoder connector. The cooling method is natural convection, and the motor operates within 0–40°C with a 23-minute thermal constant. Motor length is D and size is 070, with a mass of 14 kg. Integrated permanent magnets improve torque output and operational efficiency.

Technical Specifications

Motor Type
Synchronous

Insulation Material Class
155

Operating Modes
Rotary Main, Servo Main

Maximum Speed
6000 rpm

Winding Inductivity
3 mH

Discharge Capacity
4.5 nF

Maximum Torque
52.5 Nm

Continuous Torque
17.5 Nm

Ingress Protection
IP 65

Operating Temperature Range
0 °C to 40 °C

Thermal Time Constant
23 mins

Weight
14 kgs

Additional Feature
Equipped with permanent magnets

Frequently Asked Questions

How does MSK070D-0450-NN-M2-UP0-RNNN manage heat?

MSK070D-0450-NN-M2-UP0-RNNN is cooled with natural convection.

What special design feature is used in MSK070D-0450-NN-M2-UP0-RNNN?

MSK070D-0450-NN-M2-UP0-RNNN is designed with increased concentricity.

Does MSK070D-0450-NN-M2-UP0-RNNN have a brake system?

No, MSK070D-0450-NN-M2-UP0-RNNN does not include a holding brake.

What is the peak current of MSK070D-0450-NN-M2-UP0-RNNN?

The MSK070D-0450-NN-M2-UP0-RNNN has a maximum current rating of 49.8 A.

What torque does MSK070D-0450-NN-M2-UP0-RNNN provide continuously?

MSK070D-0450-NN-M2-UP0-RNNN produces 20.0 Nm at standstill, 100 K.

Common Misspellings

MSK070D0450NNM2UP0RNNN

MSK070D 0450 NN M2 UP0 RNNN

MSK-070D-0450-NN-M2-UP0-RNNN

MSK70D-0450-NN-M2-UP0-RNNN

Internal Product Review

The MSK070D-0450-NN-M2-UP0-RNNN delivers dependable results during extended operation. Its adaptable design highlights smooth integration into different setups. The motor emphasizes stability and trusted outcomes, reinforcing confidence in long-term use. With consistent function across workloads, it proves suitable for demanding environments requiring durable service and reliable performance under continuous operation conditions.
