R911299969 (MSK070E-0450-NN-S2-UP0-RNNN)

MSK IndraDyn S Synchronous Motors

MSK070E-0450-NN-S2-UP0-RNNN Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth MPN R911299969 (MSK070E-0450-NN-S2-UP0-RNNN) is a synchronous servomotor in the IndraDyn S series, designed with natural convection cooling and a key-equipped shaft with sealing ring. The motor features a winding inductance of 2.7 mH, a continuous current of 21.0 A for a continuous torque of 25.0 Nm at standstill (100 K), a maximum torque of 60.0 Nm, and a peak current of 57.9 A. It utilizes an EnDat2.1 singleturn optical encoder with 2048 signal periods for precise rotor feedback. The rotatable encoder connector pivots 240°, and the unit is insulated to class 155, rated IP65, and weighs 16.2 kg. The motor does not include a holding brake and supports operation between -20 to +80 °C.

Technical Specifications

Output Shaft
with keys and sealing ring

Winding Inductance
2.7 mH

Rotating Electrical Plug Degree
240-degree

Operating Speed
6000 rpm

Peak Current
57.9 A

Operating Current at 100 K
23 A

Constant torque
25 Nm

Operation Temperature
-20 and +80 degrees centigrade

Weight
16.2 kilograms

Protection Category
IP65

Insulation Class
155

Operating Condition Class
3K4

Voltage Constant
80.6 V/1000min-1

Winding Resistance at 20C
0.36 ohms

Optical feedback Encoder
Singleturn EnDat2.1

Shipping
Global

Frequently Asked Questions

Common Misspellings

Internal Product Review

The Bosch MSK070E-0450-NN-S2-UP0-RNNN synchronous motor is designed for dynamic motion control. It offers high precision in speed and position regulation. It features an optical EnDat2.1 encoder with 2048 signal periods and natural convection cooling for efficient heat dissipation. With its increased concentricity design and keyway shaft, the motor suits high-speed robotics and precision assembly systems.
