R911312437 (MSK076C-0300-NN-S1-UG0-NNNN)

MSK IndraDyn S Synchronous Motors

Rated 4.9 stars (5 total reviews)

MSK076C-0300-NN-S1-UG0-NNNN Series Image

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911312437 (MSK076C-0300-NN-S1-UG0-NNNN) is an IndraDyn S synchronous servomotor equipped with a plain shaft, rotatable 240° plug connector, and Hiperface optical singleturn encoder providing 128 signal periods resolution. It supports natural convection cooling, has a motor size of 076 with length C, and provides continuous torque of 12 Nm at 60K overtemperature and 13.5 Nm at 100K, with corresponding continuous currents of 7.2 A and 8.1 A. The unit reaches a peak torque of 43.5 Nm and a maximum current of 32.4 A. It features 4 pole pairs, winding resistance of 1.85 Ω at 20°C, a thermal time constant of 25 minutes, no holding brake, and a design conforming to IP65 with maximum permissible speed of 4700 min⁻¹.

Technical Specifications

Cooling System
70K/100K Overtemperature

Continuous Torque at 60K Standstill
12 Nm

Continuous Current at 60K Standstill
7.2 Amps

Continuous Torque at 100K Standstill
13.5 Nm

Continuous Current at 100K Standstill
8.1 A

Maximum Torque
43.5 Nm

Maximum Current
32.4 Amps

Winding Resistance at 200C
1.85 Ohms

Constant Voltage at 200C
113V/min-1

Torque Constant at 200C
1.84Nm/A

Recommended Ambient Temperature
0-40 0C

Winding Inductivity
12.6mH

Leakage Capacitance
6.5nH

Rotor Moment of Inertia with Brakes
0.0043

Pole Pairs
4

Thermal Time Constant
60 minutes

Maximum Permissible Speed
4700min-1

Degree of Protection
IP65

Sound Pressure Level
75dB(A) or less

Inertia Brake
Optional

Frequently Asked Questions

What does natural-convection cooling mean for duty cycle and thermal behavior on MSK076C-0300-NN-S1-UG0-NNNN in S1 continuous operation?

The heat is dissipated through the frame, so airflow around the motor largely defines permissible continuous torque. Its 25-minute thermal time constant smooths temperature excursions in intermittent moves but sustained overload still requires derating or supplemental machine-side cooling.

How do the 43.5 Nm maximum torque and 32.4 A peak current of MSK076C-0300-NN-S1-UG0-NNNN translate into usable overload capability?

They define short-term acceleration torque beyond continuous limits for enabling faster indexing and recovery from process disturbances. Its drive parameterization should enforce time-at-peak constraints to protect windings and maintain magnet and bearing lifetimes.

Why are 240° rotatable encoder and power connectors advantageous on the MSK076C-0300-NN-S1-UG0-NNNN during integration?

They allow optimal cable egress and strain-relief in cramped enclosures for reducing bend stress and EMI coupling. Its orientation flexibility also shortens installation time and prevents connector clashes with adjacent axes or guarding.

Is MSK076C-0300-NN-S1-UG0-NNNN interoperable with Rexroth IndraDrive controllers and third-party systems using Hiperface?

Yes, the Rexroth specifies IndraDrive compatibility for MSK series and Hiperface is widely supported for analog Sin/Cos with a digital parameter channel. The cable sets, scaling constants and encoder ID in the drive firmware is of importance to verify.

What ingress protection level is typical for MSK IndraDyn S motors used in shop-floor environments, and what should be verified for this code?

The MSK series commonly ship with IP65-class sealing for dust and low-pressure water jets in standard configurations.

Common Misspellings

Internal Product Review

The Bosch Rexroth’s IndraDyn S MSK076C-0300-NN-S1-UG0-NNNN servomotor uses a singleturn Hiperface encoder of 128 periods for speed and motion control. It comes with 240° rotatable connectors for flexible wiring and uses natural cooling. This unit is constructed with 4 pole pairs and it delivers 43.5 Nm of peak torque, while utilizes 32.4 A max current under overload. Its thermal time constant is 25 min and it suits applications such as machine tools, packaging, robotics and material handling.
