R911315027 (MSK100C-0450-NN-M1-AG0-NNNN)

Name: R911315027 (MSK100C-0450-NN-M1-AG0-NNNN)
Brand: Indramat Motors
SKU: MSK100C-0450-NN-M1-AG0-NNNN
Price: 978.00 USD
Availability: InStock
Rating: 4.6 (6 reviews)

MSK IndraDyn S Synchronous Motors

Rated 4.6 stars (6 total reviews)

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911315027 (MSK100C-0450-NN-M1-AG0-NNNN) is a Bosch Rexroth synchronous servomotor with natural convection cooling and a plain output shaft featuring a sealing ring for lubricant protection. It has a motor size of 100 and length C, with a winding code of 0450. The unit delivers 38 Nm continuous torque at 60 K with a current of 35.4 A, and is capable of up to 43.5 Nm and 43.5 A at 100 K. Maximum torque reaches 148.0 Nm with a peak current of 159.3 A. The motor is fitted with an optical multiturn absolute Hiperface encoder (128 signal periods) and includes an internal temperature sensor. The enclosure is IP65 rated, insulation class 155, engineered for operation from 0 to +40 °C and transport/storage between -20 and +80 °C. The power connector is positioned on the A-side, and there is no integrated holding brake. Winding inductivity is specified at 1,600 mH.

Technical Specifications

Internal Temperature Sensor
Yes

Encoder Type
Multiturn absolute Hiperface

Protection Degree
IP 65

Insulation Class Rating
155

Constant Torque
38 Nm

Continuous Current
35.4 A at 60 K

Operation Temperature Range
0 - 40 degrees Celsius

Relocation Temperature Range
-20 - 80 degrees Celsius

Sealing Ring
Yes

Winding Resistance
0.12 ohms

Power Connection
A Side

Heat Transfer
Natural Convection

Thermal Time Constant
90 minutes

Continuous Torque Rating (at 100 K)
43.5 Nm

Continuous Current Rating (at 100 K)
43.5 A.

Frequently Asked Questions

Why is the continuous current rating at 100 K critical for MSK100C-0450-NN-M1-AG0-NNNN?

The 43.5 A continuous current rating at 100 K reflects the motor’s thermal resilience. It indicates the motor can sustain high loads without compromising performance.

Why is continuous torque at standstill important for this motor?

It ensures the motor can hold heavy loads without overheating. This feature is vital in processes needing stable positioning under static conditions.

How does the Hiperface encoder in MSK100C-0450-NN-M1-AG0-NNNN improve system performance?

The Hiperface encoder provides precise position feedback, ensuring high accuracy in motion control. This is especially critical in applications demanding synchronization and repeatability.

What is the advantage of having 128 signal periods in the encoder?

The 128 signal periods increase resolution and improve motion accuracy. This ensures smooth operation in applications requiring precise angular positioning.

How does motor length “C” impact the MSK100C-0450-NN-M1-AG0-NNNN’s performance?

The motor length directly influences torque and thermal management. Length “C” offers a balance of compactness and higher torque capacity.

Common Misspellings

MSK 100C-0450-NN-M1-AG0-NNNN

MSK-100C-0450-NN-M1-AG0-NNNN

MSK100C 0450 NN M1 AG0 NNNN

MSK100C-0450-NN-M1-AG0

MSK100C0450NNM1AG0NNNN

MSK1OOC-O45O-NN-M1-AGO-NNNN

MSKI00C-0450-NN-MI-AG0-NNNN

Internal Product Review

The MSK100C-0450-NN-M1-AG0-NNNN is a plain shaft 100-frame motor with a built-in Hiperface encoder that provides 128 signal periods. It is made by Bosch Rexroth Indramat and used in semiconductor wafer handling equipment. Some of its main features are 43.5 A continuous current and 43.5 Nm torque during standstill.
