The R911315382 (MSK070D-0150-NN-M1-UP0-NNNN) is a Bosch Rexroth synchronous servomotor from the MSK IndraDyn S series. This model features a standard design with size 070 and length D, equipped with a shaft with keyway and operates without a holding brake. It is fitted with an optical multiturn absolute encoder using the Hiperface interface, delivering 128 signal periods and a rotatable connector (240°). The device operates within a 0°C to 40°C temperature range and is cooled by natural convection. It is suitable for use with a maximum axial force of 60N and includes a stator temperature sensor. Electrical data include a continuous standstill current of 7.1 A and torque of 20.0 Nm at 100 K, with maximum values of 24.8 A current and 52.5 Nm torque. The winding code is 0150 and the inductivity is 25,900 mH. This servomotor has four pole pairs, set bearing on the B side, and is not intended for explosive atmospheres.

Technical Specifications

Product Group
MSK

Installation
Follow specified regulations

Grounding Connection
Included

Explosion Hazard
Not suitable for explosive atmospheres

Temperature Range
0°C to 40°C

Connectors
Must be securely locked/tightened

Housing
May be hot during/after operation

Holding Brake
None

Risk of Explosion
Due to overloading

Pole Pairs
4

Encoder
Multiturn absolute, Hiperface interface

Axial Force
Max 60N

Radial Force
Must not exceed maximum

Design
Standard, fixed bearing on B side

Certifications
CE, CUL, RoHS

Cooling
Self-cooling

Temperature Sensor
Present in stato

Frequently Asked Questions

Why does MSK070D-0150-NN-M1-UP0-NNNN feature shaft with keyway?

The keyway locks the shaft for secure torque transfer. It ensures consistent performance when connecting gearboxes or couplings.

How does multiturn absolute encoder improve CNC machine positioning?

The multiturn encoder removes homing. It keeps an accurate reference even after shutdowns.

Why is 7.1 A continuous current rating beneficial?

The 7.1 A rating reduces power demand. It optimizes energy use and supports efficient drive operation during long duty cycles.

How does 240° connector flexibility help MSK070D-0150-NN-M1-UP0-NNNN?

The 240° connector allows different wiring angles. It makes installation easier in tight machine layouts.

Why is 20 Nm continuous torque essential in packaging machines?

The 20 Nm torque drives repetitive cycles reliably. It supports stable operation in continuous packaging lines.

Common Misspellings

MSK 070D-0150-NN-M1-UP0-NNNN

MSK-070D-0150-NN-M1-UP0-NNNN

MSK070D 0150 NN M1 UP0 NNNN

MSK070D-0150-NN-M1-UP0

MSK070D-0I50-NN-MI-UP0-NNNN

MSK070D0150NNM1UP0NNNN

MSKO70D-0150-NN-M1-UP0-NNNN

MSKO7OD-O15O-NN-M1-UPO-NNNN

MSK70D-0150-NN-M1-UP0-NNNN

Internal Product Review

The Bosch Rexroth MSK070D-0150-NN-M1-UP0-NNNN servomotor is a three-phase synchronous motor offering up to 52.5 Nm of torque with 6 pole pairs and a multiturn absolute encoder for precise motion control. It features a compact 070 frame size, natural convection cooling, and a rotatable encoder connector for easy installation. Commonly used in CNC machinery, robotics, and packaging lines, this motor supports accurate positioning in automated systems.
