R911320004 (MSK101E-0200-NN-M1-RG0-NNNN)
MSK IndraDyn S Synchronous Motors
Technical Specifications
Inductance
3.300 mH
Torque Constant
2.40 Nm/A
Maximum Torque Output
231 Newton meters
Design Speed
3500 revolutions per minute
Sound Pressure Level
Below 75 decibels
Thermal Time Constant
100 minutes
Transportation Temperature Range
-20 to +80 degrees Celsius
Constant Current at 60K
32.1 A
Continuous Torque at 60K
70 Nm
Operational Temperature Range
0 to +40 degrees Celsius
Constant Current at Standstill
48.2 A
Constant Torque at Standstill
105 Nm
Winding Resistance
0.18 ohms
Voltage Constant
148 V/min-1 at 20 degrees Celsius
Feedback
Multi-turn Hiperface Optical Feedback Encoder
Output Shaft
Plain with sealing ring
Recommended Settings
3K4
Distributor
Indramat USA
Frequently Asked Questions
Why is the plain shaft configuration effective for the MSK101E-0200-NN-M1-RG0-NNNN in flexible drive setups?
The uniform shaft interface allows multiple coupling types. It minimizes stress concentration and provides balanced load transfer across mechanical connections.
How does the MSK101E-0200-NN-M1-RG0-NNNN maintain clean signal flow through its 3,000 mH inductivity?
High inductance filters unwanted electrical harmonics. It delivers smooth current transitions and consistent magnetic response during rapid acceleration or deceleration cycles.
Why does the MSK101E-0200-NN-M1-RG0-NNNN perform efficiently without a holding brake?
Encoder precision compensates for position drift naturally. The motor maintains positional integrity using feedback correction, suitable for applications requiring dynamic stop-start cycles.
How does the MSK101E-0200-NN-M1-RG0-NNNN enhance drive stability during start-up?
The current control algorithm limits overshoot effectively. It achieves predictable torque buildup and prevents vibration during initial servo activation.
Why is natural convection cooling reliable for the MSK101E-0200-NN-M1-RG0-NNNN?
The passive heat transfer avoids fan dependency. It supports continuous performance while reducing mechanical wear and energy use in extended operation.
Common Misspellings
MSK101E0200NNM1RG0NNNN
MSK101E 0200 NN M1 RG0 NNNN
MSK-101E-0200-NN-M1-RG0-NNNN
Internal Product Review
The MSK101E-0200-NN-M1-RG0-NNNN synchronous motor from Bosch Rexroth Indramat operates with natural convection cooling and a plain shaft design. It has a right-side connector and multiturn optical encoder with Hiperface. This motor fits well in robotic joints and production conveyors that demand repeatable speed control.
Shipping & Payment Options
Warranty
Repair
We offer a repair service for the MSK101E-0200-NN-M1-RG0-NNNN.
