R911321715 (MSK100B-0400-NN-M1-LG0-NNNN)

Name: R911321715 (MSK100B-0400-NN-M1-LG0-NNNN)
Brand: Indramat Motors
SKU: MSK100B-0400-NN-M1-LG0-NNNN
Price: 530.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911321715 (MSK100B-0400-NN-M1-LG0-NNNN) is part of the MSK series of synchronous servo motors from Bosch Rexroth. This model features a 100 size and B length, a plain shaft, and left-side power connection. It is equipped with a multiturn absolute optical encoder (Hiperface interface, 128 signal periods), and provides 33.0 Nm continuous torque and 102.0 Nm maximum torque. The motor operates with natural convection cooling, or optional surface cooling, rated IP65 for protection. Key parameters include 30.8 A standstill continuous current at 100 K, 106.7 A maximum current, and 3,100 mH winding inductivity. Operating range: 0–40°C up to 1000 m altitude (reduced performance up to 55°C/3000 m). The unit is without a holding brake.

Technical Specifications

Operating Temperature
0 to 40 degrees Celsius

Maximum Operating Temperature with performance derating
55 degrees Celsius

Operating Altitude
0 to 1000 meters

Maximum Operating Altitude with performance derating
3000 meters

Transportation Temperature
-20 to 80 degrees Celsius

Storage Temperature
-20 to 60 degrees Celsius

IP Rating
IP65

Shaft Design
Smooth

Encoder Type
Optical Multiturn

Encoder Signal Periods
128

Holding Brake
Absent

Electrical Connection Location
Left side of housing

Cooling Method
Natural convection and surface cooling

Cooling Fan
Not included, must be ordered separately

Frequently Asked Questions

What ensures dynamic movement on the MSK100B-0400-NN-M1-LG0-NNNN?

Controlled current surges allow the MSK100B-0400-NN-M1-LG0-NNNN to produce powerful acceleration bursts, enhancing responsiveness while maintaining torque stability under short-term demand.

Which shaft configuration improves mechanical integrity on the MSK100B-0400-NN-M1-LG0-NNNN?

The MSK100B-0400-NN-M1-LG0-NNNN’s plain shaft offers zero-play coupling that minimizes vibration and preserves motion accuracy through repeated directional reversals.

How does the speed code influence tuning for the MSK100B-0400-NN-M1-LG0-NNNN?

Code 0400 in the MSK100B-0400-NN-M1-LG0-NNNN standardizes frequency control, optimizing both heat management and torque precision for predictable, repeatable results.

What is the role of inductivity in the MSK100B-0400-NN-M1-LG0-NNNN?

Winding inductivity moderates current ramps within the MSK100B-0400-NN-M1-LG0-NNNN, yielding quieter torque output and better control accuracy at variable speeds.

How is heat managed in the MSK100B-0400-NN-M1-LG0-NNNN?

The MSK100B-0400-NN-M1-LG0-NNNN employs natural convection to sustain operational temperatures, reducing maintenance needs while extending motor longevity.

Common Misspellings

MSK100B0400NNM1LG0NNNN

MSK100B 0400 NN M1 LG0 NNNN

MSK-100B-0400-NN-M1-LG0-NNNN

Internal Product Review

Designed with left-side power routing and multiturn Hiperface feedback, the MSK100B-0400-NN-M1-LG0-NNNN offers a clean installation layout that suits modular systems. Its plain shaft provides precise coupling and natural convection ensures a quiet, low-maintenance cooling method ideal for continuous-duty applications.
