R911323866 (MSK060C-0600-NN-M1-BG0-NNNN)

Name: R911323866 (MSK060C-0600-NN-M1-BG0-NNNN)
Brand: Indramat Motors
SKU: MSK060C-0600-NN-M1-BG0-NNNN
Price: 821.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 56 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911323866 (MSK060C-0600-NN-M1-BG0-NNNN) is an IndraDyn S synchronous servomotor designed for flange mounting with a plain shaft and sealing ring. It features natural convection cooling and a multiturn absolute optical Hiperface encoder with 128 signal periods, supporting electrical connector rotation of 240 degrees. The motor reaches a peak torque of 24 Nm and a maximum current of 38.0 A, with continuous torque of 8.8 Nm at 10.5 A (100 K), and operates at up to 4900 rpm. It provides IP65 protection, a noise level below 75 dB, and functions within an ambient temperature range of 0 to 40°C. The power connector is located on the B-side, and no holding brake is included.

Technical Specifications

Mounting
Flange

Installation
Driving side up or down possible

Cooling Method
Natural convection

Connector
Electrical, 240 degrees rotation

Shaft Type
Simple shaft with sealing ring

Vibrations Impact
Significant, recommended cautious use

Manual Language
Official language of the user's country

Motor Type
Synchronous servo motor

Operating Temp Range
0 to 40 degrees

Noise Level
Less than 75 decibels

IP Rating
IP65

Insulation
Category 155

Peak Torque
24 Nm

Peak Current
19.2 A

Maximum Speed
4900 rpm

Frequently Asked Questions

What cooling is used in the MSK060C-0600-NN-M1-BG0-NNNN?

The MSK060C-0600-NN-M1-BG0-NNNN uses natural convection cooling.

Where is the power connector on MSK060C-0600-NN-M1-BG0-NNNN?

The MSK060C-0600-NN-M1-BG0-NNNN has its power connector on the B-side.

What encoder interface is supported by MSK060C-0600-NN-M1-BG0-NNNN?

The MSK060C-0600-NN-M1-BG0-NNNN supports a Hiperface encoder interface.

Does MSK060C-0600-NN-M1-BG0-NNNN include a holding brake?

The MSK060C-0600-NN-M1-BG0-NNNN is built without a holding brake.

What maximum torque can MSK060C-0600-NN-M1-BG0-NNNN deliver?

The MSK060C-0600-NN-M1-BG0-NNNN delivers up to 24.0 Nm.

Common Misspellings

MSK060C0600NNM1BG0NNNN

MSK060C 0600 NN M1 BG0 NNNN

MSK-060C-0600-NN-M1-BG0-NNNN

MSK60C-0600-NN-M1-BG0-NNNN

Internal Product Review

The MSK060C-0600-NN-M1-BG0-NNNN supports smooth operation with dependable results in extended use. It integrates easily into different systems, maintaining consistent performance without unnecessary complications. The design emphasizes quality and durability, ensuring confidence in its reliability. The motor’s quiet performance and steady output make it a solid choice for demanding applications.
