R911323946 (MSK070D-0150-NN-S2-UP0-RNNN)

Name: R911323946 (MSK070D-0150-NN-S2-UP0-RNNN)
Brand: Indramat Motors
SKU: MSK070D-0150-NN-S2-UP0-RNNN
Price: 910.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

5 Minutes 0 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth synchronous servomotor R911323946 (MSK070D-0150-NN-S2-UP0-RNNN) is a compact unit with a mass of 14 kg, featuring natural convection cooling and providing continuous torque of 20.0 Nm and continuous current of 7.1 A at 100 K. It achieves a maximum torque of 52.5 Nm with a peak current of 24.8 A. The motor is equipped with a singleturn optical EnDat2.1 encoder (2048 signal periods, rotatable 240°), and a temperature sensor for thermal monitoring. The shaft utilizes a keyway with a sealing ring, and the housing is rated IP65. The winding code is 0150, winding inductivity is 25,900 mH, and the unit does not include a holding brake.

Technical Specifications

Rotating Electrical Plug
Present

Natural Convection Housing
Present

Internal Temperature Sensor
Present

Output Shaft Type
Keyways with Sealing Ring

Weight
14 kg

Winding Resistance
3.20 Ohms

Constant Torque at 100 K
20 Nm

Continuous Current Value at 100 K
7.1 A

Encoder Type
Singleturn EnDat2.1 Optical Encoder

Maximum Torque
52.5 Nm

Peak Current Consumption
24.8 A

Thermal Time Constant
23 Minutes

Moment of Inertia
0.00375 kgm2

Protection Standard
IP 65

Insulation Class
155

Constant Torque at Standstill Surface
26.3 Nm

Continuous Current at Standstill Surface
9.3 A

Frequently Asked Questions

Does the MSK070D-0150-NN-S2-UP0-RNNN motor have a holding brake?

No, the MSK070D-0150-NN-S2-UP0-RNNN motor does not include a holding brake.

What is the design type of the MSK070D-0150-NN-S2-UP0-RNNN motor?

The MSK070D-0150-NN-S2-UP0-RNNN motor is designed with increased concentricity.

What is the maximum torque of the MSK070D-0150-NN-S2-UP0-RNNN motor?

The MSK070D-0150-NN-S2-UP0-RNNN motor provides a maximum torque of 52.5 Nm.

What is the winding inductivity of the MSK070D-0150-NN-S2-UP0-RNNN motor?

The winding inductivity of the MSK070D-0150-NN-S2-UP0-RNNN motor is 25,900 mH.

What is the motor length of the MSK070D-0150-NN-S2-UP0-RNNN model?

The MSK070D-0150-NN-S2-UP0-RNNN motor has length code D.

Common Misspellings

MSK070D0150NNS2UP0RNNN

MSK070D 0150 NN S2 UP0 RNNN

MSK-070D-0150-NN-S2-UP0-RNNN

MSK70D-0150-NN-S2-UP0-RNNN

Internal Product Review

The MSK070D-0150-NN-S2-UP0-RNNN delivers consistent results during extended use. Its adaptability supports integration into varied setups with smooth performance. The motor emphasizes steady function, reinforcing confidence in long-term service. With dependable outcomes and trusted operation, it is a suitable choice for environments requiring durable results and continuous operation under demanding conditions.
