R911323959 (MSK070D-0150-NN-M2-UP0-RNNN)

Name: R911323959 (MSK070D-0150-NN-M2-UP0-RNNN)
Brand: Indramat Motors
SKU: MSK070D-0150-NN-M2-UP0-RNNN
Price: 430.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth R911323959 (MSK070D-0150-NN-M2-UP0-RNNN) is an IndraDyn S synchronous servomotor that features a shaft with a DIN 6885 keyway for form-locking torque transfer. Its shaft sealing ring offers chemical and oil resistance but is sensitive to certain liquids. This model does not include a holding brake and relies on natural convection for cooling, requiring a minimum 100 mm gap from other components for vertical heat dissipation. Motor temperature is monitored by a KTY84 sensor, which initiates shutdown at 150°C. The servomotor employs an optical multiturn absolute encoder (EnDat2.1) with 2048 signal periods and a rotatable 240° connector. Electrical specifications include a continuous current at standstill (100 K) of 7.1 A, a continuous torque at standstill (100 K) of 20.0 Nm, a maximum current of 24.8 A, and a maximum torque of 52.5 Nm. The winding inductivity is rated at 25,900 mH. Care should be taken during installation to avoid exceeding permissible shaft loads and to prevent jamming or clamping of the centering collar and to ensure a burr-free flange. Post-operation cooling time is approximately 140 minutes, during which contact with the motor should be avoided due to surface temperatures.

Technical Specifications

Shaft Design
Keyway as per DIN 6885

Sealing Ring Material
Resistant to chemicals and oils

Bearing Failure Causes
Mechanical damage, increased wear

Liquids Intrusion Effect
Can cause damage

Heat Dissipation
Natural radiation

Temperature Control
KTY84 temperature sensor

Temperature Shutdown Threshold
150°C

Placement Requirement
At least 100mm distance from adjacent components

Radial and Axial Forces
Must not be exceeded

Maintenance
Clean and free from contamination

Identification Tool
Type plate inclusive of product details

Frequently Asked Questions

How is MSK070D-0150-NN-M2-UP0-RNNN cooled?

The MSK070D-0150-NN-M2-UP0-RNNN is naturally convection-cooled.

Does MSK070D-0150-NN-M2-UP0-RNNN include a holding brake?

No, the MSK070D-0150-NN-M2-UP0-RNNN does not have a holding brake.

What design is used in MSK070D-0150-NN-M2-UP0-RNNN?

The MSK070D-0150-NN-M2-UP0-RNNN features an increased concentricity design.

What torque at standstill is available in MSK070D-0150-NN-M2-UP0-RNNN?

The MSK070D-0150-NN-M2-UP0-RNNN provides 20.0 Nm continuous torque at standstill.

What maximum torque can MSK070D-0150-NN-M2-UP0-RNNN reach?

The MSK070D-0150-NN-M2-UP0-RNNN can deliver up to 52.5 Nm maximum torque.
