R911324915 (MSK070D-0150-NN-M2-UP1-RNNN)

Name: R911324915 (MSK070D-0150-NN-M2-UP1-RNNN)
Brand: Indramat Motors
SKU: MSK070D-0150-NN-M2-UP1-RNNN
Price: 637.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The synchronous servomotor R911324915 (MSK070D-0150-NN-M2-UP1-RNNN) from the MSK size 070 series features natural convection cooling and a housing engineered for efficient heat dissipation. It provides a torque constant of 3.10 Nm/A and winding resistance of 3.20 ohms at 20°C. The motor is equipped with a shaft with keyway, a radial sealing ring resistant to oils and chemicals, and a holding brake rated at 23 Nm with electrical release. The multiturn absolute optical encoder (EnDat 2.1 interface, 2048 signal periods) supports position detection across 4096 mechanical rotations. Key electrical ratings are a continuous current of 7.1 A and 20.0 Nm continuous torque at standstill (100 K), with a maximum current of 24.8 A and a maximum torque of 52.5 Nm. The motor includes 6 pole pairs and a rotatable flange socket RLS1201 for connection.

Technical Specifications

Product
Bosch Rexroth MSK Synchronous motor

Housing design
Natural convection

Torque constant at 20 degrees C
3.10 Nm/A

Winding resistance at 20 degrees C
3.20 ohms

Pole pairs
6

Output shaft
Plain with radial sealing ring

Holding brake
23Nm, electrical release

Power connection
Flange socket RLS1201

Overvoltage category
III

Encoder system
Multiturn absolute optical EnDat 2.1

Mechanical rotations
Less than 4096

Position storage
Yes, even after power disconnection.

Frequently Asked Questions

What cooling type does MSK070D-0150-NN-M2-UP1-RNNN use?

The MSK070D-0150-NN-M2-UP1-RNNN uses natural convection cooling.

Does MSK070D-0150-NN-M2-UP1-RNNN include a brake?

Yes, the MSK070D-0150-NN-M2-UP1-RNNN features an electrically-released holding brake.

What is the holding brake torque of MSK070D-0150-NN-M2-UP1-RNNN?

The holding brake torque of the MSK070D-0150-NN-M2-UP1-RNNN is 23 Nm.

What maximum current does MSK070D-0150-NN-M2-UP1-RNNN support?

The MSK070D-0150-NN-M2-UP1-RNNN supports up to 24.8 A maximum current.

What winding inductivity is specified for MSK070D-0150-NN-M2-UP1-RNNN?

The winding inductivity of the MSK070D-0150-NN-M2-UP1-RNNN is 25,900 mH.
