R911334875 (MSK043C-0600-NN-S1-UG1-NNNN)

Name: R911334875 (MSK043C-0600-NN-S1-UG1-NNNN)
Brand: Indramat Motors
SKU: MSK043C-0600-NN-S1-UG1-NNNN
Price: 895.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911334875 (MSK043C-0600-NN-S1-UG1-NNNN) is a synchronous servo motor with an IP65 protection rating, designed for precise motion applications. It features natural convection cooling and a plain shaft with a sealing ring. The integrated singleturn hiperface optical encoder with 128 signal periods enables accurate position monitoring. The motor operates at continuous currents up to 4.7 A at 100 K and provides continuous torque of up to 3.1 Nm, with a peak torque capability of 8.1 Nm and maximum current rating of 12.4 A. The unit supports a maximum speed of 7500 RPM and is equipped with a 4 Nm electrically-released holding brake. Operating temperature range is 0 to +40 °C, sound pressure level remains below 75 dB[A], and the motor weighs 3.6 kg excluding accessories and brake.

Technical Specifications

Protection Category
IP65

Rated Current
3.6-4.3 A

Rated Torque
2.7-3.1 Nm

Maximum Speed
7500 rpm

Maximum Torque
12.5 Nm

Cooling Mode
Natural convection

Shaft Type
Plain

Weight
3.6 kg (excluding accessories and holding brake)

Holding Brake
4 Nm

Installation Temperature
0 to +40 degree Celsius

Sound Pressure Level
75 dB[A]

Discharge Capacity
2 nF

Pole Pairs
4

Frequently Asked Questions

How does the 240° rotatable connector benefit the MSK043C-0600-NN-S1-UG1-NNNN motor?

The rotatable connector of MSK043C-0600-NN-S1-UG1-NNNN motor allows flexible installation in tight spaces. This design reduces cable stress and ensures reliable electrical connections during continuous axis operation.

What is the role of the 4 Nm holding brake in this MSK043C-0600-NN-S1-UG1-NNNN motor?

The MSK043C-0600-NN-S1-UG1-NNNN motor's brake prevents shaft movement when the system is powered down. It is especially valuable in vertical axis applications to stop load drift.

Why is motor size 043 significant in industrial applications?

The compact size 043 frame makes it suitable for space-constrained systems. Despite its size, it delivers reliable torque output for mid-scale automation tasks.

What are typical applications of the MSK043C-0600-NN-S1-UG1-NNNN motor?

The MSK043C-0600-NN-S1-UG1-NNNN motor is widely used in CNC machining, robotics, and packaging automation. Its high encoder accuracy ensures efficiency in repetitive positioning tasks.

How does the rated speed code 0600 affect system compatibility?

The 0600 speed code defines motor speed-torque balance. It aligns the motor’s dynamic response with servo drives commonly used in Bosch Rexroth CNC controls.

Common Misspellings

MSK043C0600NNS1UG1NNNN

MSK043C 0600 NN S1 UG1 NNNN

MSK-043C-0600-NN-S1-UG1-NNNN

MSK43C-0600-NN-S1-UG1-NNNN

Internal Product Review

The IndraDyn S Synchronous Servomotor MSK043C-0600-NN-S1-UG1-NNNN from Bosch Rexroth delivers 3.1 Nm continuous torque with 4.7 A standstill current. It is widely used in CNC machines, robotics, and packaging systems for precise positioning. The motor features a Hiperface singleturn optical encoder and a 240° rotatable connector.
