R911335496 (MSK060B-0300-NN-M3-UG0-NNNN)

Name: R911335496 (MSK060B-0300-NN-M3-UG0-NNNN)
Brand: Indramat Motors
SKU: MSK060B-0300-NN-M3-UG0-NNNN
Price: 681.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911335496 (MSK060B-0300-NN-M3-UG0-NNNN) is an IndraDyn S synchronous servo motor designed for precision and dynamic industrial applications. It features natural convection cooling, with the option for an additional fan, and includes a temperature sensor for thermal monitoring. The motor supports a maximum speed of 4800 RPM, provides continuous torque of 5.5 Nm at 100 K, and a maximum torque of 15.0 Nm, with a continuous standstill current of 3.3 A and a maximum current of 12.0 A. It incorporates a multiturn absolute capacitive encoder (Hiperface interface, 16 signal periods), a rotatable connector (240°), and a plain shaft design, with four pole pairs. The motor tolerates axial shock loads up to 10 m/s² and radial shock loads up to 500 m/s². With an IP65 rating, it is resistant to dust and water jets. The black RAL 9005 2K epoxy coating offers additional protection against various chemicals and environmental factors. The motor length is B, size 060, and it does not include a holding brake.

Technical Specifications

Use
Factory Automation

Dynamics
High

Construction
Compact

Torque Density
High

Precision
High

Cooling Method
Natural Convection

Operating Temperature
0 - 40 °C

Axial Shock Load
10 m/s²

Radial Shock Load
500 m/s²

Maximum Speed
4800 RPM

Pole Pairs
4

Hub Connection
Non-positive and Zero-backlash Plain Shaft

Ingress Protection
IP65

Color
Black (RAL 9005)

Coating Resin
2K Epoxy

Frequently Asked Questions

What is the motor’s continuous torque rating?

The MSK060B-0300 provides a continuous torque of 5.0 Nm at 60 K rise, ensuring stable load handling. This supports long-term performance in demanding servo applications.

What is the maximum torque rating specified?

This motor delivers a maximum torque of 15.0 Nm for short overload demands. Such capacity enables reliable operation under rapid acceleration and heavy transient loads.

What is the rated continuous current consumption?

The continuous current is 3.0 A (60 K) at a standstill to support stable operation. This current rating ensures compatibility with standard drive electronics and cables.

What is the maximum effective current capacity?

The motor supports a maximum current of 12.0 A, enabling short bursts of high torque. This provides flexibility in dynamic cycles and acceleration profiles.

What is the rotor inertia specification value?

The rotor inertia is 0.00048 kg·m², influencing system response and acceleration. This makes the motor suitable for applications requiring precise positioning and fast starts.

Common Misspellings

MSK060B0300NNM3UG0NNNN

MSK060B 0300 NN M3 UG0 NNNN

MSK-060B-0300-NN-M3-UG0-NNNN

MSK60B-0300-NN-M3-UG0-NNNN

Internal Product Review

The Bosch Rexroth IndraDyn S MSK060B-0300-NN-M3-UG0-NNNN servomotor uses a capacitive multiturn absolute encoder over Hiperface with 16 signal periods and a rotatable 240° connector. It has motor size 060, length B, rated speed code 0300, and no holding brake. It suits automotive assembly, packaging, woodworking, and general manufacturing.
