R911335849 (MSK060C-0600-NN-M3-UG1-NNNN)

Name: R911335849 (MSK060C-0600-NN-M3-UG1-NNNN)
Brand: Indramat Motors
SKU: MSK060C-0600-NN-M3-UG1-NNNN
Price: 828.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911335849 (MSK060C-0600-NN-M3-UG1-NNNN) is a Bosch Rexroth IndraDyn S synchronous servomotor with a 240° rotatable connector and a multiturn absolute Hiperface encoder, providing 16 signal periods via a capacitive interface. Dimensions are 116 x 226 x 50 mm, with a standard design and black RAL 9005 housing. The plain shaft includes a sealing ring, and the motor incorporates an electrically-released holding brake rated at 10 Nm torque, to be engaged only when the motor is stationary. Rated at a thermal class of 155 (EN 60034-1) and conforming to DIN EN 60721-3-3 Class 3K4, the unit has a rotor inertia moment of 0.0008 kg·m². Electrical parameters include a winding inductivity of 8,600 mH, continuous standstill current of 10.5 A, maximum current of 38.0 A, continuous torque at standstill of 8.8 Nm, and maximum torque of 24.0 Nm. Cooling is achieved by natural convection. Performance is specified for defined ambient operating conditions, and sinusoidal vibrations may be present when stationary.

Technical Specifications

Connector Rotation
240°

Torque Density
High

Fault Detection
Yes

Holding Brake Usage
Only during standstill mode

Programming Needs
Required before startup

Use in Explosive Atmosphere
Not recommended

Thermal Class
155 (EN 60034-1)

Moment of Inertia of Rotor
0.0008kgm2

Size
116 x 226 x 50mm

Encoder
Multiturn absolute Hiperface with 4096 revolutions

Housing Varnish
RAL 9005 Black

Shaft
Plain with shaft sealing ring

Housing Delivery
Available worldwide

Thermal Coupling
Varies when fitted with transmissions

Climatic Category During Operation
Class 3K4 (DIN EN 60721-3-3)

Vibrations
Experiences sinewave oscillations when stationary

Frequently Asked Questions

Does the MSK060C-0600-NN-M3-UG1-NNNN motor include a holding brake?

Yes, the MSK060C-0600-NN-M3-UG1-NNNN motor has an electrically-released brake.

What is the holding brake torque of the MSK060C-0600-NN-M3-UG1-NNNN motor?

The MSK060C-0600-NN-M3-UG1-NNNN motor provides 10 Nm of brake torque.

What shaft design is used in the MSK060C-0600-NN-M3-UG1-NNNN motor?

The MSK060C-0600-NN-M3-UG1-NNNN motor has a plain shaft.

What is the maximum torque of the MSK060C-0600-NN-M3-UG1-NNNN motor?

The MSK060C-0600-NN-M3-UG1-NNNN motor reaches 24.0 Nm maximum torque.

What is the winding inductivity of the MSK060C-0600-NN-M3-UG1-NNNN motor?

The MSK060C-0600-NN-M3-UG1-NNNN motor has 8,600 mH winding inductivity.

Common Misspellings

MSK060C0600NNM3UG1NNNN

MSK060C 0600 NN M3 UG1 NNNN

MSK-060C-0600-NN-M3-UG1-NNNN

MSK60C-0600-NN-M3-UG1-NNNN

Internal Product Review

The MSK060C-0600-NN-M3-UG1-NNNN is regarded for consistent performance and dependable construction. It integrates easily into varied systems and runs with minimal disruption. The motor proves effective in supporting demanding applications while maintaining stability. Its reliable operation over time builds confidence, making it a trusted solution for different industrial requirements.
