R911340124 (MSK071E-0300-NN-M3-UP0-NNNN)

Name: R911340124 (MSK071E-0300-NN-M3-UP0-NNNN)
Brand: Indramat Motors
SKU: MSK071E-0300-NN-M3-UP0-NNNN
Price: 544.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Indramat MPN R911340124 (MSK071E-0300-NN-M3-UP0-NNNN) is a synchronous servomotor from the IndraDyn S series, designed for industrial automation applications. The motor utilizes natural convection for cooling and is equipped with a shaft featuring a keyway. It has a motor size of 071 and length E, with a standard design and no holding brake. The encoder is a multiturn absolute capacitive type with Hiperface interface, offering 16 signal periods and a connector rotatable up to 240 degrees. Electrical connections are made via separate power and motor feedback cables. Rated performance includes a continuous torque of 28.0 Nm and current of 15.2 A at standstill (100 K), with maximum ratings of 84.0 Nm torque and 56.3 A. The winding inductivity is specified as 5,900 mH. Ball bearings are lubricated for reduced friction and an expected service lifespan of 30,000 hours. Operational noise does not exceed 75 dB.

Technical Specifications

Rexroth Indramat Product
Yes

Type
Synchronous Industrial Motor

Recommended Operators
Trained Engineers

Lubrication
Grease Lubricated Ball Bearings

Bearings Lifespan
30,000 Hours

Noise Level
75 Decibels

Communication Channels
Power cable and Motor Feedback Cable

Connector Type
Separate Connectors for Each Cable

Flange Sockets Angle
240 Degrees

Frequently Asked Questions

What are salient features of MSK motor?

Salient features include compact size, high torque density, and high precision.

What is the approximate motor weight?

The approximate motor weight is 23.5 kg.

Where can you find detailed torque-speed curves?

Detailed torque-speed curves for MSK motors are available in the motor manual.

What is a multiturn encoder?

A multiturn encoder measures both the shaft position within one rotation and counts the number of full rotations, enabling absolute position tracking over multiple turn.

Which standard does the shaft comply with?

The shaft installed on this motor complies with the DIN 6885-1 standard.

Common Misspellings

MSK071E0300NNM3UP0NNNN

MSK071E 0300 NN M3 UP0 NNNN

MSK-071E-0300-NN-M3-UP0-NNNN

MSK71E-0300-NN-M3-UP0-NNNN

Internal Product Review

MSK071E-0300-NN-M3-UP0-NNNN is an industrial servo motor. It weighs 23.1 kilograms. Feedback, IP65 rated housing and optimum cooling make it a solution of choice for industrial applications.
