R911340909 (MSK060B-0600-NN-S3-UG0-NNNN)
MSK IndraDyn S Synchronous Motors
Technical Specifications
Product Type
MSK Motor
Design
Compact
Performance
High
Encoder Integration
Optical
Peak Current
24.4 Amperes
Max Torque
15 Nm
Max Rotations Per Minute
6000
Winding Inductivity
18 mH
Weight
6.4 kg
Insulation Class
155
Pole Pairs
4
Rotor Moment of Inertia
0.00048 kgm2
IP Rating
IP65
Blocking Brake
Not Included
Output Shaft Type
Simple with Sealing Ring
Cooling Mechanism
Natural Convection
Frame Size
060
Length
B
Electrical Connector
Plug with 240 Degrees Range
Frequently Asked Questions
What is the continuous torque rating specification?
The continuous torque rating of the MSK060B-0600-NN-S3-UG0-NNNN is 5.0 Nm at 60 K. The specification ensures stable performance during prolonged operation under moderate thermal conditions.
How does the maximum current affect motor operation?
The maximum current of 24.4 A defines the upper operating limit under peak load conditions. The value ensures short-term overload capacity without thermal damage to windings.
What is the significance of the torque constant?
The torque constant of 0.90 Nm/A determines torque generation efficiency relative to applied current. The parameter helps engineers match drive amplifiers and predict power losses effectively.
How does the winding resistance impact efficiency?
The winding resistance of 1.85 Ω affects copper losses and heat generation during current flow. The specification supports efficient energy conversion and thermal management during continuous duty cycles.
What operational benefits come from the 6000 rpm speed?
The maximum speed of 6000 rpm provides flexibility for high-dynamic applications requiring fast response. The specification allows precise motion control across varied load and acceleration conditions.
Common Misspellings
MSK060B0600NNS3UG0NNNN
MSK060B 0600 NN S3 UG0 NNNN
MSK-060B-0600-NN-S3-UG0-NNNN
MSK60B-0600-NN-S3-UG0-NNNN
Internal Product Review
The Bosch Rexroth MSK060B-0600-NN-S3-UG0-NNNN IndraDyn S Synchronous Servomotor offers precise positioning with a singleturn capacitive encoder, 16 signal periods, and a Hiperface interface. It features a natural convection cooling, 5.5 Nm continuous torque, and 15 Nm peak torque with a 10 Nm holding brake. It supports reliable performance in robotics, conveyor systems, and advanced printing equipment.
