R911343147 (MSK101E-0200-NN-M3-AG0-NNNN)

Name: R911343147 (MSK101E-0200-NN-M3-AG0-NNNN)
Brand: Indramat Motors
SKU: MSK101E-0200-NN-M3-AG0-NNNN
Price: 397.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911343147 (MSK101E-0200-NN-M3-AG0-NNNN) is an IndraDyn S synchronous servomotor with motor size 101 and length E, designed for applications requiring precise motion control. It features a plain output shaft, no holding brake, and uses natural convection cooling. The motor is equipped with a multiturn absolute capacitive encoder (Hiperface interface, 16 signal periods resolution), providing ±20 angular seconds system accuracy and position retention after power off. The nominal continuous current at standstill (100 K) is 39.0 A, with a continuous torque of 80.5 Nm and a maximum current of 144.5 A, delivering up to 231.0 Nm maximum torque. Power is connected on the A-side. The winding code is 0200, with a winding inductivity of 3,000 mH. Operation above 50°C may lead to mechanical failure due to thermal constraints.

Technical Specifications

Usage
rotary main and industrial servo motor

Encoder
Multi-turn optical encoder

System Accuracy
± 20 angular seconds

Output Shaft
Plain type

Sealing Ring
Shaft sealing ring

Nominal Input Current
32 ampere

Max Input Current
144.5 ampere

Max Operable Temperature
50 degrees Celsius.

Frequently Asked Questions

How does the MSK101E-0200-NN-M3-AG0-NNNN sustain torque accuracy under static load?

Its 3,000 mH inductivity balances magnetic flux efficiently. This keeps torque linear and prevents drift during prolonged stationary positioning in servo applications.

Why does the MSK101E-0200-NN-M3-AG0-NNNN use a capacitive multiturn encoder?

The capacitive sensing eliminates optical interference effects. This ensures stable signal feedback and dependable position recovery during extended operational cycles.

How does the MSK101E-0200-NN-M3-AG0-NNNN benefit from 16 signal period resolution?

It delivers finely segmented positional data for precise feedback. This improves motion fidelity and reduces angular deviation across repetitive actuation cycles.

How does the MSK101E-0200-NN-M3-AG0-NNNN achieve quick setup through its A-side connector?

Front-mounted power access streamlines electrical integration. It shortens installation time and improves wiring alignment in compact automation panels.

Why is the plain-shaft design effective for the MSK101E-0200-NN-M3-AG0-NNNN?

It allows flexible coupling selection for multiple transmissions. This reduces mechanical backlash and supports precise torque transfer under dynamic load transitions.

Common Misspellings

MSK101E0200NNM3AG0NNNN

MSK101E 0200 NN M3 AG0 NNNN

MSK-101E-0200-NN-M3-AG0-NNNN

Internal Product Review

The MSK101E-0200-NN-M3-AG0-NNNN synchronous motor from Bosch Rexroth Indramat combines capacitive Hiperface feedback with 16 signal periods. It uses an A-side connector and natural convection cooling. Its compact plain-shaft frame suits conveyor drives and assembly robots that value efficiency and steady motion precision.
