R911343150 (MSK060C-0300-NN-M3-UG0-NNNN)

Name: R911343150 (MSK060C-0300-NN-M3-UG0-NNNN)
Brand: Indramat Motors
SKU: MSK060C-0300-NN-M3-UG0-NNNN
Price: 896.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

4 Minutes 37 Seconds

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911343150 (MSK060C-0300-NN-M3-UG0-NNNN) is an IndraDyn S Synchronous Servomotor from the Bosch Rexroth MSK series, designed for use as a rotary main or servo drive in industrial applications such as machine tools and packaging equipment. This unit features a capacitive multiturn absolute encoder with 16 signal periods, an encoder connector rotatable up to 240°, and uses the Hiperface interface. The motor has a plain shaft with sealing ring, a motor size of 060, and a motor length C. It operates without a holding brake, employs natural convection cooling, and is built to IP65 housing protection standards. The motor's winding code is 0300, providing a continuous current at standstill (100 K) of 5.3 A, continuous torque at standstill (100 K) of 8.8 Nm, maximum current of 19.2 A, maximum torque of 24.0 Nm, winding resistance of 3.1 Ohms at 20°C, and winding inductance of 35,900 mH. The thermal class is F, and it performs optimally in ambient temperatures from 0°C to 40°C.

Technical Specifications

Product Line
MSK Bosch Rexroth

Application
Rotary main and servo drive motors

Design
Standard housing

Encoder
Capacitive, 16 signal periods

Shaft
Plain with sealing ring

Connectors
240-degree rotatable power/feedback

Cooling Method
Natural convection

Working Temperature Range
0 to 40 degrees Celsius

Housing Protection Rating
IP65

Thermal Class
F as per EN 60034-1

Winding Resistance at 20 degrees Celsius
3.1 Ohms

Winding Inductance
2.1 millihenry

Brake
No Holding Brake

Frequently Asked Questions

What brake option is on MSK060C-0300-NN-M3-UG0-NNNN?

The MSK060C-0300-NN-M3-UG0-NNNN has no holding brake.

Which shaft design comes with MSK060C-0300-NN-M3-UG0-NNNN?

MSK060C-0300-NN-M3-UG0-NNNN is built with a plain shaft.

How does MSK060C-0300-NN-M3-UG0-NNNN manage heat?

MSK060C-0300-NN-M3-UG0-NNNN relies on natural convection cooling.

What encoder interface is in MSK060C-0300-NN-M3-UG0-NNNN?

The MSK060C-0300-NN-M3-UG0-NNNN features Hiperface.

What is the encoder resolution of MSK060C-0300-NN-M3-UG0-NNNN?

MSK060C-0300-NN-M3-UG0-NNNN delivers 16 signal periods.

Common Misspellings

MSK060C0300NNM3UG0NNNN

MSK060C 0300 NN M3 UG0 NNNN

MSK-060C-0300-NN-M3-UG0-NNNN

MSK60C-0300-NN-M3-UG0-NNNN

Internal Product Review

The MSK060C-0300-NN-M3-UG0-NNNN delivers smooth performance with consistent reliability. It runs quietly and supports stable operation across extended use. Installation is straightforward, making it adaptable to different systems. Its construction feels solid and dependable. The motor provides steady results in challenging applications, giving users confidence in long-term performance and operational consistency.
