R911343350 (MSK070E-0300-NN-M3-UP1-NNNN)

Name: R911343350 (MSK070E-0300-NN-M3-UP1-NNNN)
Brand: Indramat Motors
SKU: MSK070E-0300-NN-M3-UP1-NNNN
Price: 254.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911343350 (MSK070E-0300-NN-M3-UP1-NNNN) is a Bosch Rexroth IndraDyn S synchronous servomotor designed for applications requiring high dynamic response and precise control. It features natural convection cooling, shaft with keyway and radial seal, and an electrically-released holding brake with a torque of 23 Nm. The optical multiturn absolute encoder uses Hiperface interface and provides 16 signal periods and +/-80 angular seconds accuracy. The continuous current at standstill (100 K) is 16.7 A, and continuous torque is 25.0 Nm, with peaks of 49.3 A and 65.0 Nm respectively. The motor includes a rotatable (240°) encoder connector, 3,900 mH winding inductivity, is size 070 with length E, and is suitable for operation at ambient temperatures up to 40°C and 95% relative humidity.

Technical Specifications

Type
Synchronous Motor

Encoder
Optical multiturn absolute

Encoder Interface
Hiperface

System Accuracy
+/- 80 angular seconds

Shaft
With keyway and radial shaft sealing ring

Max Ambient Temperature
40C

Max Relative Humidity
95%

Construction
Compact

Frequently Asked Questions

What encoder technology does the MSK070E-0300-NN-M3-UP1-NNNN motor use?

It uses capacitive encoder technology provides high-resolution position feedback. This enables precise control of the motor’s movements.

What makes the MSK070E-0300-NN-M3-UP1-NNNN motor suitable for high-precision tasks?

The capacitive encoder provides high-resolution feedback. This allows precise position control for applications requiring exact and repeatable movements.

How does the MSK070E-0300-NN-M3-UP1-NNNN motor handle thermal stress?

The motor uses natural convection cooling. This effectively dissipates heat and ensures stable performance during continuous operation.

Why does the MSK070E-0300-NN-M3-UP1-NNNN motor use a plain shaft design?

The plain shaft design simplifies integration. It reduces mechanical complexity, making the motor versatile for various applications and configurations.

What is the rated speed code for the MSK070E-0300-NN-M3-UP1-NNNN motor?

The rated speed code is 0300. This indicates the motor’s optimal operating speed under standard conditions.

Common Misspellings

MSK070E0300NNM3UP1NNNN

MSK070E 0300 NN M3 UP1 NNNN

MSK-070E-0300-NN-M3-UP1-NNNN

MSK70E-0300-NN-M3-UP1-NNNN

Internal Product Review

The Bosch Rexroth Indramat MSK070E-0300-NN-M2-UP0-RNNN synchronous motor is designed for high-precision motion control. It uses a capacitive encoder with an EnDat2.1 interface and delivers 25 Nm continuous torque and 65 Nm peak torque. Its natural convection cooling ensures efficient performance.
