R911370783 (MSK060C-0600-NN-S3-UP1-NNNN)

MSK IndraDyn S Synchronous Motors

  In Stock, Ships Today
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The Bosch Rexroth R911370783 (MSK060C-0600-NN-S3-UP1-NNNN) synchronous servomotor from the IndraDyn S series integrates a capacitive singleturn encoder (16 signal periods, Hiperface interface) and features a shaft with keyway and a 10 Nm electrically-released holding brake. This motor type utilizes natural convection cooling in a standard-rated housing (IP65) and supports 240-degree rotatable connectors. Continuous torque at standstill is 8.8 Nm (10.5 A, at 100 K), with maximal values of 24.0 Nm torque and 38.0 A current; maximum speed is 6000 RPM. The unit weighs 9.2 kg and is suitable for operation between 0 °C and 40 °C.

Technical Specifications

Connectors
Two, 240-degree rotatable

Holding Brake
20 Nm holding torque

Housing Design
Standard

Cooling Method
Natural convection

Continuous Torque at Standstill
8 Nm

Continuous Current at Standstill
9.5 Amps

Peak Motor Torque
24 Nm

Peak Motor Current
38 Amps

Thermal Time Constant
14 minutes

Maximum Rated Speed
6000 RPM

Weight
9.2 kilograms (including holding brake)

Protection Rating
IP65 (total dust protection)

Installation
To be performed by trained personnel.
