R911373048 (MSK071E-0300-NN-S3-UP0-NNNN)

MSK IndraDyn S Synchronous Motors

MSK071E-0300-NN-S3-UP0-NNNN Series Image

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911373048 (MSK071E-0300-NN-S3-UP0-NNNN) is an IndraDyn S synchronous servomotor designed for industrial automation. It features a natural convection cooling system, a rotatable encoder connector (240°), Hiperface-compatible capacitive encoder with singleturn functionality, and a resolution of 16 signal periods. The motor is sized 071, length E, uses winding code 0300, and incorporates a shaft with keyway in accordance with DIN 6885 for torque transmission. It operates at continuous current of 15.2 A at standstill (100 K), continuous torque of 28.0 Nm at standstill (100 K), maximum current of 56.3 A, and maximum torque of 84.0 Nm, with winding inductivity of 5,900 mH. Speed capability reaches up to 4200 RPM. The unit operates within a temperature range of 0 to 40°C and tolerates storage temperatures up to 75°C. Holding brake is not included. The motor is integrated with a standard design, robust housing, and connects to a compatible drive controller via two primary plug-in connections.

Technical Specifications

Type
Industrial Synchronous Motor

Installation
Safe and straightforward

Material
Highly durable housing unit

Protection Level
High

Connections
Power connector and Encoder connection

Operating Ambient Temperature
0 to 40 degrees Celsius

Storage Ambient Temperature
Up to 75 degrees Celsius

Output Shaft Material
Steel

Output Shaft Key
Optional, according to DIN 6885

Maximum Speed
4200 RPM

Frequently Asked Questions

Common Misspellings

Internal Product Review

MSK071E-0300-NN-S3-UP0-NNNN is a motor with a dustproof housing. Its housing also provides strong liquid ingress protection. This servo motor is equipped for feedback which enables accurate speed control.
