R911374989 (MSK070D-0300-NN-M3-UP0-NNNN)

Name: R911374989 (MSK070D-0300-NN-M3-UP0-NNNN)
Brand: Indramat Motors
SKU: MSK070D-0300-NN-M3-UP0-NNNN
Price: 642.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911374989 (MSK070D-0300-NN-M3-UP0-NNNN) is an MSK synchronous servomotor within the IndraDyn S series, designed for applications in automation requiring precise rotary control. This model is characterized by a shaft with keyway and a shaft sealing ring enabling zero-backlash, non-positive shaft-hub connections. It operates with a maximum current of 33.0 A and a winding inductivity of 6,000 mH. The continuous current at standstill is rated at 12.6 A (100 K), providing a continuous torque of 20.0 Nm and a maximum torque of 52.5 Nm. The unit is equipped with a capacitive multiturn absolute encoder (Hiperface, 16 signal periods) and a 240° rotatable encoder connector. It is constructed with six pole pairs, a thermal time constant of 32 minutes, and a bearing life of 30,000 hours. The motor utilizes natural convection for self-cooling and produces a maximum sound pressure level of 75 dB(A). The exterior is coated for resistance to seawater and acids.

Technical Specifications

Product Type
Synchronous Motor

Winding Inductivity
6.000mH

Max Current
33.0A

Coat Color
Prime Black

Torque Constant at 20*C
1.75Nm/A

Plug Orientation
240° Rotatable

Shaft Type
With Shaft Sealing Ring

Thermal Time Constant
32mins

Bearing Lifetime
30,000 Operating Hours

Cooling Type
Self-Cooling per Natural Convection

Motor Encoder
Integrated

Pole Pairs
Six

Sound Pressure Level
Less Than 75dB(A).

Frequently Asked Questions

Does MSK070D-0300-NN-M3-UP0-NNNN include a brake?

No, the MSK070D-0300-NN-M3-UP0-NNNN is built without a holding brake.

What is the design style of MSK070D-0300-NN-M3-UP0-NNNN?

The MSK070D-0300-NN-M3-UP0-NNNN follows a standard design layout.

What is the continuous torque of MSK070D-0300-NN-M3-UP0-NNNN?

The MSK070D-0300-NN-M3-UP0-NNNN provides 20.0 Nm continuous torque at standstill.

What is the maximum current rating of MSK070D-0300-NN-M3-UP0-NNNN?

The MSK070D-0300-NN-M3-UP0-NNNN has a maximum current rating of 33.0 A.

What motor size does MSK070D-0300-NN-M3-UP0-NNNN belong to?

The MSK070D-0300-NN-M3-UP0-NNNN belongs to motor size 070.

Common Misspellings

MSK070D0300NNM3UP0NNNN

MSK070D 0300 NN M3 UP0 NNNN

MSK-070D-0300-NN-M3-UP0-NNNN

MSK70D-0300-NN-M3-UP0-NNNN

Internal Product Review

The MSK070D-0300-NN-M3-UP0-NNNN demonstrates reliable operation across varied applications. Its adaptable design emphasizes smooth integration into diverse environments. The motor delivers steady outcomes and trusted results during extended service. With dependable function maintained over time, it proves effective for continuous workloads requiring lasting performance and reliable operation across challenging usage conditions and tasks.
