R911375131 (MSK071E-0300-NN-M1-AP2-NNAN)

Name: R911375131 (MSK071E-0300-NN-M1-AP2-NNAN)
Brand: Indramat Motors
SKU: MSK071E-0300-NN-M1-AP2-NNAN
Price: 227.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 1-2 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The R911375131 (MSK071E-0300-NN-M1-AP2-NNAN) is an IndraDyn S Synchronous Servomotor designed for industrial environments, featuring IP65-rated protection against dust and water. It uses natural convection for cooling and includes a shaft with keyway. The integrated multiturn absolute optical encoder with Hiperface interface supports 128 signal periods. At a housing overtemperature of 60K, the motor delivers 12.5 A and 28 Nm continuous torque. For winding overtemperature of 100K, it operates at 15.2 A with 34.5 Nm torque. Maximum output reaches 84 Nm torque at 56.3 A and a speed of 4200 RPM. The holding brake, electrically released, provides 30 Nm holding torque. Winding inductivity is specified at 5,900 mH, and the sound pressure level is below 75 dB. Power connector is on the A-side.

Technical Specifications

Use
Industrial Motor

Protection Class
IP65

Housing Overtemperature
60 kelvin

Current at 60K Housing Overtemperature
12.5 amperes

Continuous Torque at 60K
28 newton meters

Winding Overtemperature
100 kelvin

Current at 100K Winding Overtemperature
15.2 amperes

Continuous Torque at 100K
34.5 newton meters

Maximum Input Current
56.3 amperes

Maximum Torque
84 newton meters

Maximum Speed
4200 Revolutions Per Minute

Sound Pressure During Operation
75 decibels

Frequently Asked Questions

Is the motor shaft standards compliant?

The motor shaft complies with the DIN 6885-1 standard.

Which type of brake is installed on the motor?

An electrically-released brake is installed on the motor.

What is the holding torque of the brake?

Holding torque of the brake is 30 Nm.

Where is the product documentation available?

The product documentation is available for download from the manufacturer website.

Does the motor support overload protection?

Thermal monitoring is used to prevent overload damage.

Common Misspellings

MSK071E0300NNM1AP2NNAN

MSK071E 0300 NN M1 AP2 NNAN

MSK-071E-0300-NN-M1-AP2-NNAN

MSK71E-0300-NN-M1-AP2-NNAN

Internal Product Review

MSK071E-0300-NN-M1-AP2-NNAN is a motor with a holding brake. This servo motor is designed for 3-phase AC input. Its is controlled by a Bosch motor controller, that ensure accurate speed control.
