R911375466 (MSK043C-0600-NN-M3-UG1-NNNN)

Name: R911375466 (MSK043C-0600-NN-M3-UG1-NNNN)
Brand: Indramat Motors
SKU: MSK043C-0600-NN-M3-UG1-NNNN
Price: 481.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Right

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The synchronous servo motor R911375466 (MSK043C-0600-NN-M3-UG1-NNNN) is equipped with a capacitive multiturn absolute encoder featuring 16 signal periods and utilizing Hiperface interface technology. The unit supports operation at ambient temperatures up to 40°C. Performance data include a continuous torque of 2.7 Nm at 60K and 3.1 Nm at 100K temperature rise, with corresponding continuous currents of 3.6 A and 4.7 A at standstill. Maximum speed reaches 12,000 RPM and maximum torque is 8.1 Nm, while the winding inductance is 21,300 mH. The servo motor features a plain shaft with a standard sealing ring, an electrically released holding brake with 4 Nm holding torque, and a 240° rotatable power connector. The design utilizes convection cooling and requires unobstructed airflow. Installation and commissioning must follow safety instructions as per technical documentation.

Technical Specifications

MotorType
Synchronous Servo Motor

60KDataContinuousTorque
2.7

60KDataContinuousCurrent
3.6 Amps

100KDataContinuousTorque
3.1

100KDataContinuousCurrent
4.3 Amps

EncoderType
Capacitive Absolute Multi-Turn

EncoderSignalPeriods
16

MaximumEncoderSpeed
12000 RPM

MaximumEncoderCurrent
50 milliamps

EncoderSupplyVoltage
7 to 12 Volts DC

PowerConnectorOrientation
240-degree rotatable

ShaftType
plain shaft with standard sealing ring

HoldingBrakeTorque
4 Nm

CoolingType
Convection

OperationalTemperature
0 and 40 degrees Celsius

MaximumMotorSpeed
7500 RPM

ProtectionRating
IP65

Weight
3.6 kilograms

Frequently Asked Questions

What benefits does the capacitive encoder technology provide in the MSK043C-0600-NN-M3-UG1-NNNN?

Capacitive encoder technology ensures high accuracy and reliability in detecting position, improving motor performance in precise applications.

Why does the MSK043C-0600-NN-M3-UG1-NNNN use a multiturn absolute encoder?

The multiturn absolute encoder offers a precise and consistent feedback over multiple revolutions, crucial for maintaining accurate positioning in complex systems.

What advantage does the Hiperface interface offer in the MSK043C-0600-NN-M3-UG1-NNNN?

The Hiperface interface provides high-speed data transmission with increased reliability, which is ideal for industrial automation systems requiring fast and precise control.

What is the significance of the 16 signal periods resolution in the MSK043C-0600-NN-M3-UG1-NNNN encoder?

The 16 signal periods resolution allows for finer position resolution, leading to enhanced motor control precision and smoother motion.

How does the 4 Nm holding brake in the MSK043C-0600-NN-M3-UG1-NNNN improve safety?

The holding brake prevents the motor shaft from rotating when powered off, ensuring that the system remains securely in place, especially in critical applications.

Common Misspellings

MSK043C0600NNM3UG1NNNN

MSK043C 0600 NN M3 UG1 NNNN

MSK-043C-0600-NN-M3-UG1-NNNN

MSK43C-0600-NN-M3-UG1-NNNN

Internal Product Review

The MSK043C-0600-NN-M3-UG1-NNNN servomotor from Bosch Rexroth offers 3.1 Nm continuous torque and uses a multiturn absolute capacitive encoder with Hiperface interface. It includes a holding brake with 4 Nm torque and supports natural convection cooling. This motor is suitable for use in packaging, robotics, and semiconductor equipment.
