R911387101 (MSK060C-0600-NN-M3-UP0-NNNN)

Name: R911387101 (MSK060C-0600-NN-M3-UP0-NNNN)
Brand: Indramat Motors
SKU: MSK060C-0600-NN-M3-UP0-NNNN
Price: 591.00 USD
Availability: InStock

MSK IndraDyn S Synchronous Motors

Front Left

In-Stock, Ships 3-5 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
sales@indramat-usa.com

The Bosch Rexroth MPN R911387101 (MSK060C-0600-NN-M3-UP0-NNNN) is an IndraDyn S synchronous servomotor designed for applications utilizing natural convection cooling and features a winding code of 0600. The unit has an IP65 rated housing and output shaft compliant with EN 60034-5 and includes a DIN 6885-1 keyway with a radial shaft sealing ring. It supports both vertical and horizontal installation orientations. Maximum axial shock load resistance is 100 m/s² for 11 ms, and the bearing lifespan is approximately 30,000 hours per ISO 281. The motor is fitted with a KTY 84 temperature sensor, does not include a holding brake, and employs a multiturn absolute, capacitive Hiperface encoder system with a rotatable 240° connector, 16 signal periods, and standard design. Continuous current at standstill (100 K) is 10.5 A, continuous standstill torque is 8.8 Nm, maximum current is 38.0 A, maximum torque is 24.0 Nm, and winding inductivity is 8,600 mH. The shaft is equipped with a removable protective sleeve for assembly.

Technical Specifications

Degree of Protection for Housing
IP 65

Degree of Protection for Output Shaft
IP 65

Winding Code
600

Cooling Mechanism
Natural convection

Maximal Axial Shock Load
100m/s2 for 11ms

Installation
Horizontal and Vertical

Holding Brake
No

Shaft Details
Keyway shaft in accordance with DIN 6885-1

Bearing Lifespan
30,000 operating hours according to ISO 281

Temperature Sensor
KTY 84 type fitted in stator

Voltage Rise Limit
Specified limits

Damage Checks
After a storage period of more than one year

Included Elements
Protection sleeves on plug connections and shaft.

Frequently Asked Questions

Does the MSK060C-0600-NN-M3-UP0-NNNN motor include a holding brake?

No, the MSK060C-0600-NN-M3-UP0-NNNN motor has no holding brake.

What shaft type is offered on the MSK060C-0600-NN-M3-UP0-NNNN motor?

The MSK060C-0600-NN-M3-UP0-NNNN motor features a shaft with keyway.

Where is the power connector on the MSK060C-0600-NN-M3-UP0-NNNN motor?

The MSK060C-0600-NN-M3-UP0-NNNN motor has the connector on the B-side.

What is the continuous torque at standstill of the MSK060C-0600-NN-M3-UP0-NNNN motor?

The MSK060C-0600-NN-M3-UP0-NNNN motor provides 8.8 Nm at 100 K.

What is the continuous current of the MSK060C-0600-NN-M3-UP0-NNNN motor?

The MSK060C-0600-NN-M3-UP0-NNNN motor requires 10.5 A at 100 K.
