The R911392034 (MSK060C-0600-NN-M1-BP0-NNNN) is a synchronous servomotor from the IndraDyn S series by Bosch Rexroth, featuring frame size 060 and length C. It is equipped with an optical multiturn absolute encoder using the Hiperface interface, providing ±80 angular seconds of system accuracy and 128 signal periods of encoder resolution. The motor includes a shaft with keyway conforming to DIN 6885-1 and operates with 4 pole pairs. Key specifications include a maximum speed of 6,000 rpm, maximum torque of 24.0 Nm, continuous torque at standstill (100 K) of 8.8 Nm, continuous current at standstill (100 K) of 10.5 A, maximum current of 38.0 A, and winding inductivity of 8,600 mH. It is cooled by natural convection and allows for optional fan mounting. Protection category is IP65, and operational limits include an ambient temperature range of 0–40°C and relative humidity up to 95%.

Technical Specifications

Frame Size
060

Frame Length
C

System Accuracy
±80 Angular Seconds

Heat Dissipation
Natural Convection

Pole Pairs
4

Thermal Time Constant
14.0 mins

Maximum Speed
6000 Revolutions Per Minute

Maximum Torque
24.0 Nm

Operating Ambient Temperature
0o C - 40o C

Maximum Relative Air Humidity
95%

Protection Category
IP 65.

Frequently Asked Questions

What shaft type is on MSK060C-0600-NN-M1-BP0-NNNN?

The MSK060C-0600-NN-M1-BP0-NNNN features a shaft with keyway.

What is the encoder resolution of MSK060C-0600-NN-M1-BP0-NNNN?

The MSK060C-0600-NN-M1-BP0-NNNN encoder offers 128 signal periods.

What is the rated torque at standstill for MSK060C-0600-NN-M1-BP0-NNNN?

The MSK060C-0600-NN-M1-BP0-NNNN delivers 8.8 Nm at standstill.

Which encoder type is built into MSK060C-0600-NN-M1-BP0-NNNN?

The MSK060C-0600-NN-M1-BP0-NNNN is equipped with an optical encoder.

What is the continuous current for MSK060C-0600-NN-M1-BP0-NNNN?

The MSK060C-0600-NN-M1-BP0-NNNN requires 10.5 A continuous current.
