R911170086 (PSI6300.360-L1)

PSI Frequency Inverters

Call For Quote

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Current response time:

3 Minutes 28 Seconds

Phone:
1-888-551-3082

Email:
[email protected]

The Bosch Rexroth R911170086 (PSI6300.360-L1) is a medium-frequency inverter, specifically designed for resistance seam, projection, and spot-welding applications. Equipped with 1,000Hz medium-frequency or DC technology, it incorporates an integrated control function, an inbuilt weld timer, and has a maximum thermal constant current rating of 220A. This member of the PSi series is required to be used solely in industrial environments, adhering to DIN EN 50081-2 and 50082-2 specifications, with an IP 20 protection rating. The installation setting should maintain an environmental temperature not exceeding 55°C, and be clear of metal vapors, salts, and corrosive agents. Moreover, the unit follows Class F humidity standards as per the DIN 40040 specifications, utilising a metal oxide varistor for over-voltage protection. The unit offers a maximum output current of 800A, with an operating frequency of 50-60Hz, and guarantees global delivery with a one-year warranty.

Technical Specifications

Application
Resistance Seam, Projection, and Spot-Welding

Thermal Constant Current Rating
220A

Control Function
Integrated

CE Certification
Conforms

Operating Environment Specifications
DIN EN 50081-2 and 50082-2

Protection Rating
IP 20

Required Switchgear Cabinet Rating
IP 54

Operating Frequency
50-60Hz

Installation Clearance
100mm (Top and Bottom)

Maximum Ambient Operating Temperature
55°C

Humidity Class
Class F (According to DIN 40040)

Over-Voltage Protection
Metal Oxide Varistor

Maximum Installation Elevation
2000m

Maximum Output Current Rating
800A

Clocking Frequency
1kHz

Mounting
Vertical
