R911170900 (CML65.1-3P-500-NA-NNNN-NW)

CML IndraControl Hardware

In Stock, Ships Today

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911170900 (CML65.1-3P-500-NA-NNNN-NW) is an IndraControl L65 control main unit designed for industrial automation applications. It features a 1.0 GHz Intel Celeron M processor, 256 MB DRAM, 1 GB flash memory, and 512 MB internal application memory. The unit is equipped with 8 decoupled DC digital inputs (interrupt-capable), a 1-line LCD for settings and diagnostics, and standardized communication interfaces including TCP/IP Ethernet, Sercos II, and PROFIBUS. The control unit operates on a 24 V supply, has a 20 W power consumption, includes an integrated real-time clock, and conforms to IP20 protection with an inline housing. It supports up to 8-slot onboard I/O expandable to 512, offers fanless operation, and is specified for an operating temperature range of +5 °C to +55 °C and 5–95% relative humidity per EN 61131-2.

Technical Specifications

Product Type
IndraControl L65 controls

Onboard I/O slots
8 (expandable to 512)

Processor
1.0 GHz Intel Celeron

Memory
1 gigabyte flash memory

Communication Interfaces
Standardized

Visualization Components
High-Grade

Ethernet Port
Standard TCP/IP

Degree of Protection
IP 54

Integrated Display
Yes

Fieldbus Interface
Configurable

Operating Temperature
+5 oC to +55 oC

Relative Humidity
5% to 95% per EN 61131-2
