The R911174057 (CML75.1-3P-905-NA-NNNN-NW) model, manufactured by Bosch Rexroth, is an efficient industrial automation controller unit, primarily used in CNC machines, food processing, packaging machines, and assembly systems. This compact, 1.5 kg model uses a 1.75 GHz Intel Atom E3827 DualCore processor for high processing power. The L75.1 controller provides protection from 15 g shocks and 12.5 mm solid particles owing to the EN 60068-2-27 standard and IP20 protection category. It operates within a supply voltage range of 19-30 VDC and has SERCOS 3 and PROFIBUS interfaces for effective communication with I/O devices. Additional features include 8 digital inputs and outputs, a built-in 4GB DRAM memory, a compact flash card slot, and an operating panel consisting of a 1-line display with 4 keys. A 3V lithium battery ensures a service life of at least 5 years. Indramat USA ships this model globally, offering a one-year warranty.

Technical Specifications

Net Weight
1.5kg

Shock Resistance
15g according to EN 60068-2-27

Solid Particle Protection
12.5 mm

Protection Category
IP20

Processor
1.75 GHz Intel Atom E3827 DualCore

DC link voltage
24VDC

Supply Voltage Range
19VDC to 30VDC

Residual ripple
±5%

Interface Type
SERCOS 3, PROFIBUS

Cooling Type
Ambient air

Digital Inputs
8

Digital Outputs
8

Operating Panel
1-line display, 4 keys

Battery
3V Lithium, service life minimum 5 years

Ambient Temperature Range
+5 to +55 degree Celsius.
