DDS02.2-W200-BA35-01-FW

The Bosch Rexroth Indramat DDS02.2-W200-BA35-01-FW from the DDS Drive Controllers series is engineered for high-performance motion control applications. This servo drive delivers a rated current of 200 A using an internal cooling system to maintain optimum junction temperatures. It supports both digital servo feedback and resolver feedback for precise position and speed control. Command communication is handled via an analog communication module, with alternatives including SERCOS and single-axis positioning interfaces for versatile integration.

Built for robust operation, the DDS02.2-W200-BA35-01-FW is specified to function in ambient temperatures from 0 to 45 °C and altitudes up to 1 000 m without derating. When either limit is exceeded, the load factor is multiplied proportionally, ensuring predictable performance under challenging conditions. The unit is housed in an IP20, vertically mounted enclosure that dissipates heat by drawing cool air in at the bottom and exhausting warm air at the top. To maintain continuous operation, larger cabinets or dedicated air-conditioning may be required to preserve the internal environment.

The modular architecture comprises a basic unit, a separately ordered firmware, a software module that stores operating parameters, and up to three optional hardware modules for extended functionality. In the event of drive replacement, the software module can be swiftly transferred, minimizing system downtime and simplifying commissioning. Only trained professionals should install or operate this controller to ensure compliance with safety and performance standards.
